Joule-Thomson expansion of the regular(Bardeen)-AdS black hole

Sen Guo; Jin Pu; Qing-Quan Jiang; Xiao-Tao Zu

doi:10.1088/1674-1137/44/3/035102

Chinese Physics C> 2020, Vol. 44> Issue(3) : 035102 DOI: 10.1088/1674-1137/44/3/035102

Joule-Thomson expansion of the regular(Bardeen)-AdS black hole

Sen Guo ¹ ,
Jin Pu ^1,2,, ,
Qing-Quan Jiang ^1,2 ,
Xiao-Tao Zu ²

1.
College of Physics and Space Science, China West Normal University, Nanchong 637002, China
2.
School of Physics, University of Electronic Science and Technology of China, Chengdu 610054, China

Abstract
HTML
Reference
Related

PDF

Abstract：
We study the Joule-Thomson expansion of the regular black hole in an anti-de Sitter background, and obtain the inversion temperature for the Bardeen-AdS black hole in the extended phase space. We investigate the isenthalpic and inversion curves for the Bardeen-AdS black hole in the T-P plane and find that the intersection points between them are exactly the inversion points discriminating the heating from the cooling process. The inversion curve for the regular(Bardeen)-AdS black hole is not closed and there is only a lower inversion curve, in contrast to the Van der Waals fluid. Most importantly, we find that the ratio between the minimum inversion temperature and the critical temperature for the regular(Bardeen)-AdS black hole is 0.536622, which is larger than any known ratio for the singular black hole. The large ratio for the Bardeen-AdS black hole may be due to the repulsive de Sitter core near the origin of the regular black hole.
- Joule-Thomson expansion ,
- inversion curve ,
- inversion temperature ,
- the regular(Bardeen)-AdS black hole

1. Introduction

1. Introduction
2. Thermodynamics of the Bardeen-AdS black hole
3. The Joule-Thomson expansion
3.1 The Van der Waals fluid
3.2 The Bardeen-AdS black hole
4. Conclusions and discussion

It is well known that a black hole as a thermodynamic system has many interesting properties. It sets a fundamental connection between the laws of classical thermodynamics, quantum mechanics and general relativity. The thermodynamic properties of black holes have been extensively investigated since the first studies of Bekenstein and Hawking [1-6]. As thermodynamic systems, black holes have many similarities with general thermodynamic systems. For black holes in the AdS space, these similarities become more obvious and precise. Hawking and Page have pioneered the study of the phase transition between the Schwarzschild-AdS black hole and the thermal AdS space [7], and Chamblin and Emparan found the relation between the charged AdS black hole and the Van der Waals liquid-gas system [8, 9].

Recently, black hole thermodynamics in the AdS space has been intensively studied in the extended phase space where the cosmological constant is considered as the thermodynamic pressure

$P = -\frac{\Lambda}{8\pi},$

(1)

and its conjugate quantity as the thermodynamic volume [10, 11]

$V = {\Big(\frac{\partial M}{\partial P}\Big)}_{S,Q,J},$

(2)

which can enrich the AdS black hole thermodynamics. Further studies have shown that the charged AdS black hole is similar to the Van der Waals liquid-gas in the extended phase space [12], and that the $P-V$ criticality of the black hole system behaves similarly to the Van der Waals system [12-31]. In [32-35], it was found that black holes have second-order and third-order phase transitions, in addition to the Van der Waals-like phase transition.

Apart from phase transitions and critical phenomena, the thermodynamic analogy between the AdS black hole and the Van der Waals system has been creatively generalized to the well known Joule-Thomson expansion process. In classical thermodynamics, the Joule-Thomson expansion means that a fluid passes at high pressure through a porous plug into a region of low pressure, such that its enthalpy is constant. In [36], Ökcü and Aydıner investigated the Joule-Thomson expansion of the charged RN-AdS black hole in the extended phase space, and obtained the inversion and isenthalpic curves and the heating-cooling regions in the $T-P$ plane. Subsequently, this pioneering work has been generalized to other kinds of black holes, such as the quintessence charged AdS black hole [37], the Kerr-AdS black hole [38], d-dimensional charged AdS black holes [39], holographic super-fluids [40], charged AdS black hole in $f(r)$ gravity [41], AdS black hole with a global monopole [42], AdS black holes in Lovelock gravity [43], charged Gauss-Bonnet black holes [44], AdS black hole in Einstien-Maxwell axion theory and the AdS black hole in massive gravity [45] and [46-51].

However, the above mentioned Joule-Thomson expansion processes are only applicable to the AdS black holes with singularities. For the regular black hole without singularity, the Joule-Thomson expansion has not been discussed so far. Bardeen has obtained the first solution of the regular black hole with nonsingular geometry satisfying the weak energy condition [52]. Subsequently, Ayón-Beato and García proved that the Bardeen black hole can be interpreted as a gravitationally collapsed magnetic monopole arising from a specific form of non-linear electrodynamics [53]. The stability of the Bardeen-like regular black holes was studied by Moreno and Sarbach [54], and the thermodynamic properties of these black holes were discussed in [55-63]. Recently, Tzikas found the Bardeen-AdS black hole thermodynamic system criticality and the first order small/large black hole phase transition, with critical exponents that are exactly the same as those of the Van der Waals gas [64]. Obviously, the phase transition and the $P-V$ criticality of the AdS black hole are independent of the spacetime with or without singularity. In this paper, taking the regular (Bardeen)-AdS black hole as an example, we attempt to find the dependence of the spacetime without singularity on the Joule-Thomson expansion.

The paper are organized as follows. In Sec. 2, we review the thermodynamic properties of the Bardeen-AdS black hole in the extended phase space, and obtain the state equation of the black hole. In Sec. 3, we apply the Joule-Thomson expansion of the Van der Waals fluid and the Bardeen-AdS black hole, and plot the inversion and isenthalpic curves to determine the cooling and heating regions in the $T-P$ plane. The conclusions are given in Sec. 4. We use the units $G_{N} = \hbar =$ $\kappa_{B} = c = 1$ .

2. Thermodynamics of the Bardeen-AdS black hole

1. Introduction
2. Thermodynamics of the Bardeen-AdS black hole
3. The Joule-Thomson expansion
3.1 The Van der Waals fluid
3.2 The Bardeen-AdS black hole
4. Conclusions and discussion

In this section, we briefly review the thermodynamic properties of the Bardeen-AdS black hole in the extended phase space. The physical interpretation of the Bardeen metric was given Ayon-Beato and García, describing a black hole with a nonlinear magnetic monopole which results in a solution of the Einstein equations coupled to nonlinear electrodynamics [53]. The corresponding action with a negative $\Lambda$ term is expressed as [64]

${\cal{S}} = \frac{1}{16\pi}\int {\rm d}^{4}x \sqrt{-g}\left(R+\frac{6}{l^{2}}-4{\pounds}(F)\right),$

(3)

where R and g are the Ricci scalar and the determinant of the metric tensor. l is the positive AdS radius, which is related to $\Lambda$ by the relation $\Lambda = -3/l^{2}$ . $\pounds(F)$ is the Lagrangian density of the electromagnetic field, with $F = \frac{1}{4}F^{\mu\nu}F_{\mu\nu}$ , which can be expressed by [63, 64]

$\pounds(F) = \frac{3}{2s q^2}{\left(\frac{\sqrt{2q^2 F}}{1+\sqrt{2q^2 F}}\right)}^{\frac{5}{2}},$

(4)

where the parameter s is $\frac{q}{2M}$ , and q and M correspond to the magnetic charge and mass of the black hole. The field strength of the non-linear electrodynamics $F_{\mu\nu}$ is given by [63]

$F_{\mu\nu} = 2(\nabla_\mu \triangle_\nu-\nabla_\nu \triangle_\mu).$

(5)

The field equations-of-motion derived from the action in Eq. (3) is given by [63-65]

$\begin{split} {G_{\mu \nu }} + \Lambda {g_{\mu \nu }} =& 2\left(\frac{{\partial \pounds(F)}}{{\partial F}}{F_{\mu \nu }}F_\nu ^\lambda - {g_{\mu \nu }}\pounds(F)\right),\\ {\nabla _\mu }\left(\frac{{\partial \pounds(F)}}{{\partial F}}{F^{\mu \nu }}\right) =& 0,\\ {\nabla _\mu }(*{F^{\nu \mu }}) =& 0, \end{split}$

(6)

where $G_{\mu \nu}$ is the well known Einstein tensor.

The line element of the Bardeen-AdS black hole is then given by [64]

${\rm d}s^{2} = -{\Big(1-\frac{2m(r)}{r}\Big)}{\rm d}t^{2}+{\Big(1-\frac{2m(r)}{r}\Big)}^{-1}{\rm d}r^{2}+r^{2}{{\rm d}\Omega}^{2},$

(7)

where ${{\rm d}\Omega}^{2} = {{\rm d}\theta}^{2}+{\sin}^{2}{\theta}{{\rm d}\phi}^{2}$ . From Eq. (7), and with the help of Eq. (6), one finds [65]

$F_{\mu \nu} = 2 \delta^{\theta}[_{\mu}\delta^{\phi}_{\nu}]q(r)\sin \theta.$

(8)

The condition ${\rm d}F = \frac{{\rm d}q}{{\rm d}r}\sin \theta {\rm d}r \bigwedge {\rm d}\theta \bigwedge {\rm d}\phi = 0$ leads to the conclusion that $q(r) = {\rm con}st. = q$ . Hence, the magnetic field strength is given by [66]

$F_{\theta \phi} = q \sin \theta,$

(9)

and

$F = \frac{q^2}{4 r^4}.$

(10)

By substituting F from Eq. (10) into Eq. (4), one obtains [64-66]

$\pounds(F) = \pounds(r) = \frac{3M q^2}{({r^2+q^2)}^{\frac{5}{2}}}.$

(11)

The above field motion equations yield a solution for $m(r)$ that reads

$m(r) = \frac{Mr^{3}}{{(q^{2}+r^{2})}^{\frac{3}{2}}}-\frac{r^{3}}{2l^{2}}.$

(12)

The Bardeen-AdS metric potential can be expressed as [65]

$f(r) = 1-\frac{2 M r^{2}}{{(q^{2}+r^{2})}^{\frac{3}{2}}}+\frac{r^{2}}{l^{2}}.$

(13)

The event horizon $r_h$ of the black hole can be obtained as the largest root of $f(r_{h}) = 0$ . From Eq. (13), the mass M of the black hole can be written as

$M = \frac{(l^{2}+{r^2_{h}}){(q^{2}+{r^2_{h}})}^{\frac{3}{2}}}{2l^{2}{r^2_{h}}}.$

(14)

In the extended phase space, the cosmological term defines the pressure of the system Eq. (1) along with its conjugate quantity [10, 13], so that the black hole pressure is expressed as

$P = \frac{3}{8\pi l^{2}}.$

(15)

According to the area law, the entropy is given by [1, 2, 4]

$S = \frac{A}{4} = \pi r^2_h.$

(16)

We consider the mass M of the black hole as a function of entropy S, pressure P and charge q, i.e. $M = M(S,P,q)$ (see Eqs. (14), (15) and (16)), so that the mass M of the black hole can be reformulated as

$M = \frac{(\pi q^2+S)^{3/2}(3+8PS)}{6\sqrt{\pi}S}.$

(17)

The first law of thermodynamics of the black hole is given by

${\rm d}M = T{\rm d}S+V{\rm d}P+{\varphi}{{\rm d}q},$

(18)

and all thermodynamic variables defined above can be obtained as follows

$T = \Big(\frac{\partial M}{\partial S}\Big)_{P,q},\; \;\; V = \Big(\frac{\partial M}{\partial P}\Big)_{S,q},\; \;\; \varphi = {\Big(\frac{\partial M}{\partial q}\Big)}_{S,P}.$

(19)

According to Eqs. (17) and (19), the temperature of the black hole is

$T = \frac{\sqrt{q^2+S/\pi}(S+8PS^2-2\pi q^2)}{4S^2}.$

(20)

In fact, for regular black holes, there is an inconsistency between the first law and the area law. When studying the thermodynamic properties of these black holes, one has to abandon one in order for the other to work [60, 63, 67-73]. Here, we choose the Bekenstein-Hawking area law, and abandon the first law of black hole thermodynamics [68-70]. The black hole volume is given by

$V = \frac{4\pi}{3}\left(q^2+\frac{S}{\pi}\right)^{\frac{3}{2}}.$

(21)

Similarly, we have

${\varphi} = \frac{\pi q(3+8PS)\sqrt{q^2+S/\pi}}{2S}.$

(22)

One can combine these thermodynamical quantities to obtain the Smarr relation, which can be expressed as

$M = 2TS-2PV+\varphi q.$

(23)

Moreover, combining the expressions for thermodynamic pressure Eq. (15), entropy Eq. (16) and temperature Eq. (20), we get the equation-of-state of the black hole as follows

$P = \frac{T}{2\sqrt{q^2+r^2_{h}}}-\frac{1}{8 \pi r^2_{h}}+\frac{q^{2}}{4\pi {r^4_{h}}}.$

(24)

At the critical point, we have [13]

$\frac{\partial P}{\partial r_{h}} = \frac{{\partial}^{2} P}{{\partial}{r^2_{h}}} = 0,$

(25)

and the critical temperature $T_{\rm c}$ is obtained as

$T_{\rm c} = \frac{25(31+13\sqrt{10})}{432(5+2\sqrt{10})^{\frac{3}{2}}\pi q}.$

(26)

In this section, we have presented some thermodynamic quantities of the Bardeen-AdS black hole in the extended space. In the next section, we use these quantities to investigate the Joule-Thomson expansion of the black hole.

3. The Joule-Thomson expansion

1. Introduction
2. Thermodynamics of the Bardeen-AdS black hole
3. The Joule-Thomson expansion
3.1 The Van der Waals fluid
3.2 The Bardeen-AdS black hole
4. Conclusions and discussion

In this section, we study the Joule-Thomson expansion of the Bardeen-AdS black hole and compare it with the well known expansion of the Van der Waals fluid. The Joule-Thomson expansion is a classic physical process with the important property that the temperature changes with pressure and enthalpy are constant during the expansion process [74]. Hence, the Joule-Thomson expansion of a black hole is an isenthalpy process in the extended phase space. The Joule-Thomson coefficient $\mu$ , whose sign can be used to determine whether heating or cooling occurs, is defined via the change of temperature with respect to pressure as

$\mu = {\Big(\frac{\partial T}{\partial P}\Big)}_{H}.$

(27)

Since the pressure always decreases during the expansion process, the change of pressure is negative, which may cause the temperature to decrease or increase during the process. Therefore, the change of temperature determines the sign of $\mu$ . If $\mu$ is negative (positive), heating (cooling) occurs, and the fluid warms (cools). In the extended phase space, we compare a black hole system to a Van der Waals fluid with a fixed number of particles, so that we should consider the canonical ensemble with a fixed charge q. The Joule-Thomson coefficient is then given by [36]

$\mu = {\Big(\frac{\partial T}{\partial P}\Big)}_{M} = \frac{1}{C_p}\Big[T\Big({\frac{\partial V}{\partial T}}\Big)_P-V\Big].$

(28)

Setting $\mu = 0$ , we can obtain the inversion temperature, i.e.

$T_{i} = V {\Big(\frac{\partial T}{\partial V}\Big)}_{P}.$

(29)

In the next subsection, we use the Joule-Thomson coefficient Eqs. (27) and (28) to determine the inversion curves for the Van der Waals fluid and the Bardeen-AdS black hole in the extended phase space. The inversion temperatures are also obtained from Eq. (29).

3.1 The Van der Waals fluid

1. Introduction
2. Thermodynamics of the Bardeen-AdS black hole
3. The Joule-Thomson expansion
3.1 The Van der Waals fluid
3.2 The Bardeen-AdS black hole
4. Conclusions and discussion

It is well known that the Van der Waals equation is an improvement of the ideal gas equation, and is obtained by taking into account the size of the gas molecules and the interactions between them, which are ignored in the ideal gas. Hence, the gas-liquid phase transition behavior of the actual fluids is better described [74, 75]. The Van der Waals equation is given as [75]

$P = \frac{k_{B}T}{\nu-b}-\frac{a}{\nu^{2}},$

(30)

and the Joule-Thomson expansion of the Van der Waals system is obtained in [36]. The inversion temperature of the Van der Waals system is obtained as

$T_{i} = \frac{2(5a-3b^{2}P_{i}\pm 4\sqrt{a^{2}-3ab^{2}P_{i}})}{9bk_{B}},$

(31)

and the inversion curves for the Van der Waals system is plotted in Fig. 1. Moreover, the minimum and maximum inversion temperatures can be obtained as

Figure 1

Figure 1. (color online) The inversion curves for the Van der Waals fluid. The red(blue) line corresponds to the lower(upper) inversion curve.

DownLoad: Full-Size Img PowerPoint

$T^{\rm min}_i = \frac{2a}{9bk_{B}},\; \; \; T^{\rm max}_i = \frac{2a}{bk_{B}}.$

(32)

The critical temperature of the Van der Waals fluid is given by $T_{\rm c} = 8a/(27bk_B)$ , and the ratio between the inversion temperature and the critical temperature is

$\frac{T^{\rm min}_i}{T_{\rm c}} = \frac{3}{4},\; \; \; \frac{T^{\rm max}_i}{T_{\rm c}} = \frac{27}{4}.$

(33)

3.2 The Bardeen-AdS black hole

1. Introduction
2. Thermodynamics of the Bardeen-AdS black hole
3. The Joule-Thomson expansion
3.1 The Van der Waals fluid
3.2 The Bardeen-AdS black hole
4. Conclusions and discussion

In this subsection, we investigate the Joule-Thomson expansion of the Bardeen-AdS black hole in the extended phase space. The characteristic feature of the expansion is that the temperature changes with pressure, while enthalpy remains constant during the expansion process. We know from [13] that the mass of the black hole is determined as the enthalpy in the AdS space, so that the mass of the black hole remains constant during the expansion process. In our case, by observing carefully the expressions for these thermodynamic quantities, we find a simpler method to derive the Joule-Thomson coefficient $\mu$ . From Eqs. (14) and (15), the pressure P can be rewritten as a function of ${M}$ and $r_h$ , i.e.

$P({M},{r}_{h}) = \frac{6M{r^2_{h}}-3{(q^{2}+{r^2_{h}})}^{\frac{3}{2}}}{8\pi{r^2_{h}}(q^{2}+r^2_h)^{\frac{3}{2}}},$

(34)

and substituting $P(M,r_h)$ into Eq. (20) for temperature yields

$T({M},{r}_{h}) = \frac{3Mr^4_h-(q^2+r^2_h)^{\frac{5}{2}}}{2\pi r^4_h(q^2+r^2_h)}.$

(35)

From the relations between the Joule-Thomson coefficient $\mu$ , pressure $P({M},{r}_{h})$ and temperature $T({M},{r}_{h})$ , one can obtain a simple expression

$\mu = {\Big(\frac{\partial T}{\partial P}\Big)}_{M} = {\Big(\frac{\partial T}{\partial {r_{h}}}\Big)}_{M}{\Big(\frac{\partial {r_{h}}}{\partial P}\Big)}_{M} = \frac{\Big(\partial T/\partial {r_{h}\Big)}_{M}}{\Big(\partial P/\partial {r_{h}}\Big)_{M}}.$

(36)

Then, setting $\mu = 0$ in Eq. (36), one can get

$8\pi P_{i}r^6_h+2r^4_h-5q^2r^2_h-4q^4 = 0.$

(37)

By solving Eq. (37) for $r_h(P_i)$ , one can get a positive and real root which has a physical meaning, and the corresponding pressure $P_i$ in the root is the inversion pressure. Substituting the root into Eq. (20) for temperature, one can obtain the inversion temperature $T_i$ . Since these expressions are too complex, they are not explicitly given here.

From the expression for the inversion temperature $T_i$ , we obtain the inversion temperature curves for the Bardeen-AdS black hole shown in Fig. 2. The curves are shown for different values of charge q. It can be seen that the inversion temperature for a given pressure increases with q. Compared with the inversion curve for the Van der Waals fluid, we also see that the inversion curves for the black hole are not closed, as there are only lower inversion curves. This means that during the Joule-Thomson expansion process, the black hole always cools above the inversion curve, as previously described in [36-51].

Figure 2

Figure 2. (color online) The inversion curves for the Bardeen-AdS black hole in the

$T-P$ plane. From bottom to top, the inversion curves correspond to

$q = 1,2,3,4$ .

DownLoad: Full-Size Img PowerPoint

If we set the inversion pressure $P_i$ to zero, the minimum inversion temperature is given by

${T_{i}}^{\rm min} = \frac{\sqrt{9+\sqrt{57}}(\sqrt{57}-3)}{2(5+\sqrt{57})^2 \pi q}.$

(38)

The ratio between the minimum inversion temperature and the critical temperature is given by

$\frac{{T_{i}}^{\rm min}}{T_{\rm c}}{\approx} 0.536622.$

(39)

The ratio between the minimum inversion temperature and the critical temperature for the Bardeen-AdS black hole is smaller than for the Van der Waals fluid (0.75), but is larger than any known ratio for the singular black hole. The large ratio is universal for the regular black hole, in contrast to the singular black hole, and it should therefore be related to some specific property of the regular black hole. In fact, there is a repulsive de Sitter core near the origin of the regular black hole, which is not present in the singular black hole (see in Sec. 4).

In Fig. 3, we plot the isenthalpic (constant mass) and inversion curves for different values of charge q in the $T-P$ plane. We can see that the inversion curves divide the plane into two regions. The region above the inversion curves corresponds to the cooling region, while the region below the inversion curves corresponds to the heating region. In fact, the heating and cooling regions are determined by the sign of the slope of the isenthalpic curves. It is positive in the cooling region and negative in the heating region. The inversion curve acts as a boundary between the two regions, and neither cooling nor heating occurs on the inversion curve itself.

Figure 3

Figure 3. (color online) The inversion and isenthalpic (constant mass) curves for the Bardeen-AdS black hole. The blue (black) lines are the inversion (isenthalpic) curves. From bottom to top, the isenthalpic curves correspond to an increasing mass

${M}$ of the black hole. Top left:

$q = 1$ and

$M = 2,2.5,3,3.5$ . Top right:

$q = 2$ and

$M = 5,5.5,6,6.5$ . Bottom left:

$q = 3$ and

$M = 8,8.5,9,9.5$ . Bottom right:

$q = 4$ and

$M = 12,12.5,13,13.5$ .

DownLoad: Full-Size Img PowerPoint

Finally, we list the ratio between the minimum inversion temperature and the critical temperature for various black holes in Table 1. We easily see that the ratio for the Bardeen-AdS black hole is higher than for the singular black holes.

Table 1

Table 1. The ratio between the minimum inversion temperature and the critical temperature for various black holes.

type	ratio	literature
${\rm van-der-Waals-fluid}$	0.75	[36]
${\rm RN-AdS}$	0.5	[36]
${\rm quintessence-AdS}$	$0.5$	[37]
${\rm Kerr-AdS}$	0.5	[38]
${\rm d-dimensional-AdS}$	<0.5	[39]
${\rm holographic-super-fluids}$	0.4864	[40]
$f(r)-{\rm gravity}$	0.5	[41]
${\rm global-monopole}$	0.5	[42]
${\rm Lovelock-gravity}$	<0.4389	[43]
${\rm Gauss-bonnet}$	0.4765	[44]
${\rm Einstien-Maxwell-axions-theory}$	0.5	[45]
${\rm massive-gravity}$	0.4626	[46]
${\rm Bardeen}$	0.536622

DownLoad: CSV

Show Table

4. Conclusions and discussion

1. Introduction
2. Thermodynamics of the Bardeen-AdS black hole
3. The Joule-Thomson expansion
3.1 The Van der Waals fluid
3.2 The Bardeen-AdS black hole
4. Conclusions and discussion

In this paper, we investigated the Joule-Thomson expansion of the Bardeen-AdS black hole in the extended phase space, where the cosmological constant is viewed as pressure and the black hole mass as enthalpy. We first reviewed the thermodynamic properties of the Bardeen-AdS black hole in the extended phase space and obtained its equation-of-state. We then plotted for the Joule-Thomson expansion of the Van der Waals fluid, the inversion curves and determined the cooling and heating regions in the $T-P$ plane. We also investigated the Joule-Thomson expansion of the Bardeen-AdS black hole, and plotted the related inversion curves. In contrast to the Van der Waals fluid, the inversion curves for the Bardeen-AdS black hole are not closed, and there only exists a lower inversion curve. In addition, we have plotted the inversion and isenthalpic curves for the Bardeen-AdS black hole in the $T-P$ plane, and determined the cooling and heating regions for various values of charge q and mass M. It was shown that the isenthalpic curves have positive slope above the inversion curves where cooling occurs, while the sign of the slope is negative below the inversion curves where heating occurs.

The ratio between the minimum inversion temperature and critical temperature for the Bardeen-AdS black hole is smaller than for the Van der Waals fluid (0.75), but is larger than any known ratio for the singular black hole. The large ratio is universal for the regular black hole, in contrast to the singular black hole, and it should therefore be related to a specific property of the regular black hole. In fact, for large distances ( $r\gg q$ ), the Bardeen-AdS black hole coincides with the conventional Schwarzschild-AdS black hole with $f(r)\approx 1-\frac{2M}{r}+\frac{r^2}{l^2}$ . Near the origin ( $r\ll q$ ), the Bardeen-AdS black hole could be described by a line element where $f(r)\approx 1-\Big(\frac{2Ml^2}{q^3}-1\Big)\frac{r^2}{l^2}$ . According to the metric potential, the origin can be seen as: i) a repulsive de Sitter core when $2Ml^2>q^3$ ; ii) an attractive Anti de Sitter core when $2Ml^2<q^3$ ; iii) a local Minkowski core with no gravitational interaction when $2Ml^2 = q^3$ . Obviously, when the origin is an attractive Anti de Sitter core or a local Minkowski core, there is no horizon. Therefore, the Bardeen-AdS black hole exists only in the case of a repulsive de Sitter core at the origin. There is in any case a repulsive de Sitter core in a regular(Bardeen)-AdS black hole, in contrast to the singular black hole. Thus, we conclude that the large ratio for the regular(Bardeen)-AdS black hole may be due to the repulsive de Sitter core near the origin of the regular black hole. On the other hand, for the Van der Waals fluid, there exists a repulsive volume, in contrast to the ideal fluid, and studies have shown that in this case the ratio between the minimum inversion temperature and critical temperature is always larger than for the singular black hole. Therefore, it is reasonable to assume that a repulsive de Sitter core near the origin of the regular(Bardeen)-AdS black hole leads to the large ratio of these temperatures.

After we have completed this paper, a similar study appeared in arXiv:1904.09548.

References

[1]	J. D. Bekenstein, Lett. Nuovo Cimento, 4: 737-740 (1972) doi: 10.1007/BF02757029
[2]	J. D. Bekenstein, Phys. Rev. D, 7: 2333-2346 (1973)
[3]	J. M. Bardeen, B. Carter, and S. W. Hawking, Commun. Math. Phys., 31: 161-170 (1973) doi: 10.1007/BF01645742
[4]	J. D. Bekenstein, Phys. Rev. D, 9: 3292-3300 (1974)
[5]	S. W. Hawking, Nature, 248: 30-31 (1974) doi: 10.1038/248030a0
[6]	S. W. Hawking, Commun. Math. Phys., 43: 199-220 (1975), [Erratum: Commun. Math. Phys. 46: 206 (1976)]
[7]	S. W. Hawking and D. N. Page, Commun. Math. Phys., 87: 577 (1983) doi: 10.1007/BF01208266
[8]	A. Chamblin, R. Emparan, C. V. Johnson et al, Phys. Rev. D, 60: 064018 (1999) doi: 10.1103/PhysRevD.60.064018
[9]	A. Chamblin, R. Emparan, C. V. Johnson et al, Phys. Rev. D, 60: 104026 (1999) doi: 10.1103/PhysRevD.60.104026
[10]	M. Cvetic, G. W. Gibbons, D. Kubiznak et al, Phys. Rev. D, 84: 024037 (2011) doi: 10.1103/PhysRevD.84.024037
[11]	B. P. Dolan, D. Kastor, D. Kubiznak et al, Phys. Rev. D, 87: 104017 (2013) doi: 10.1103/PhysRevD.87.104017
[12]	D. Kubiznak and R. B. Mann, JHEP, 1207: 033 (2012)
[13]	D. Kastor, S. Ray, and J. Traschen, Class. Quant. Grav., 26: 195011 (2009) doi: 10.1088/0264-9381/26/19/195011
[14]	B. P. Dolan, Class. Quant. Grav., 28: 235017 (2011) doi: 10.1088/0264-9381/28/23/235017
[15]	S. Gunasekaran, R. B. Mann, and D. Kubiznak, JHEP, 1211: 110 (2012)
[16]	S. W. Wei and Y. X. Liu, Phys. Rev. D, 87: 044014 (2013) doi: 10.1103/PhysRevD.87.044014
[17]	A. Belhaj, M. Chabab, H. El Moumni et al, Chin. Phys. Lett., 30: 100401 (2012)
[18]	S. H. Hendi and M. H. Vahidinia, Phys. Rev. D, 88: 084045 (2013) doi: 10.1103/PhysRevD.88.084045
[19]	S. B. Chen, X. F. Liu, and C. Q. Liu, Chin. Phys. Lett., 30: 060401 (2013) doi: 10.1088/0256-307X/30/6/060401
[20]	E. Spallucci and A. Smailagic, Phys. Lett. B, 723: 436-441 (2013) doi: 10.1016/j.physletb.2013.05.038
[21]	R. Zhao, H. H. Zhao, M. S. Ma et al, Eur. Phys. J. C, 73: 2645 (2013) doi: 10.1140/epjc/s10052-013-2645-x
[22]	A. Belhaj, M. Chabab, H. E. Moumni et al, JHEP, 05: 149 (2015)
[23]	N. Altamirano, D. Kubiznak, and R. B. Mann, Phys. Rev. D, 88: 101502 (2013) doi: 10.1103/PhysRevD.88.101502
[24]	R. G. Cai, L. M. Cao, L. Li et al, JHEP, 1309: 005 (2013)
[25]	S. H. Hendi, and A. Dehghani, Eur. Phys. J. C, 79: 227 (2019) doi: 10.1140/epjc/s10052-019-6743-2
[26]	B. Liu, Z. Y. Yang, and R. H. Yue, Tricritical point and solid/liquid/gas phase transition of higher dimensional AdS black hole in massive gravity, arXiv: 1810.07885
[27]	S. W. Wei, P. Cheng, and Y. X. Liu, Phy. Rev. D, 93: 084015 (2016) doi: 10.1103/PhysRevD.93.084015
[28]	Z. Sun and M. S. Ma, EPL, 122: 60002 (2018) doi: 10.1209/0295-5075/122/60002
[29]	G. Miao and Z. M. Xu, Eur. Phys. J. C, 77: 403 (2017) doi: 10.1140/epjc/s10052-017-4978-3
[30]	J. Liang, C. B. Sun, and H. T. Feng, EPL, 113: 30008 (2016) doi: 10.1209/0295-5075/113/30008
[31]	J. Xu, L. M. Cao, Y. P. Hu, Phys. Rev. D, 91: 124033 (2015) doi: 10.1103/PhysRevD.91.124033
[32]	D. Kastor, S. Ray, and J. Traschen, Class. Quant. Grav., 27: 235014 (2010) doi: 10.1088/0264-9381/27/23/235014
[33]	N. Altamirano, D. Kubiznak, R. B. Mann et al, Class. Quant. Grav., 31: 042001 (2014) doi: 10.1088/0264-9381/31/4/042001
[34]	A. M. Frassino, D. Kubiznak, R. B. Mann et al, JHEP, 1409: 80 (2014)
[35]	R. A. Hennigar and R. B. Mann, Entropy, 17: 8056-8072 (2015) doi: 10.3390/e17127862
[36]	O. Ökcü and E. Aydıner, Eur. Phys. J. C, 77: 24 (2017) doi: 10.1140/epjc/s10052-017-4598-y
[37]	H. Ghaffarnejad, E. Yaraie, and M. Farsam, Int. J. Theo. Phys, 57: 1671-1682 (2018) doi: 10.1007/s10773-018-3693-7
[38]	O. Ökcü and E. Aydıner, Eur. Phys. J. C, 78: 123 (2018) doi: 10.1140/epjc/s10052-018-5602-x
[39]	J. X. Mo, G. Q. Li, S. Q. Lan et al, Phys. Rev. D, 98: 124032 (2018) doi: 10.1103/PhysRevD.98.124032
[40]	R. D’Almeida and K. P. Yogendran, Thermodynamic Properties of Holographic superfluids, arXiv: 1802.05116
[41]	M. Chabab, H. E. Moumni, S. Iraoui et al, LHEP, 2: 05 (2018)
[42]	C. L. A. Rizwan, A. N. Kumara, D. Vaid et al, Int. J. Mod. Phys., 33: 1850210 (2018) doi: 10.1142/S0217751X1850210X
[43]	J. X. Mo and G. Q. Li, Effects of Lovelock gravity on the JouleThomson expansion, arXiv: 1805.04327
[44]	S. Q. Lan, Phys. Rev. D, 98: 084014 (2018) doi: 10.1103/PhysRevD.98.084014
[45]	S. Q. Hu, Joule-Thomson expansion in AdS black holes with momentum relaxation, arXiv: 1808.07392
[46]	A. Haldar and R. Biswas, EPL., 123: 40005 (2018) doi: 10.1209/0295-5075/123/40005
[47]	Z. W. Zhao, Y. H. Xiu, and N. Li, Phys. Rev. D, 93: 124003 (2018)
[48]	A. Cisterna, S. Q. Hu, and X. M. Kuang, Joule-Thomson expansion in AdS black holes with momentum relaxation, arXiv: 1808.07392 [gr-qc]
[49]	D. M. Yekta, A. Hadikhani, and O. Ökcü, Phys. Lett. B, 795: 521-527 (2019) doi: 10.1016/j.physletb.2019.06.049
[50]	Z. W. Zhao, Y. H. Xiu, and N. Li, Phys. Rev. D, 93: 124003 (2018)
[51]	S. Q. Lan, Nucl. Phys. B, 948: 114787 (2019) doi: 10.1016/j.nuclphysb.2019.114787
[52]	J. M. Bardeen, Non-singular general-relativistic gravitational collapse, Proceedings of GR5, Tbilisi, Georgia, USSR, p. 174 (1968)
[53]	E. Ayón-Beato and A. García, Phys. Lett. B, 493: 149-152 (2000) doi: 10.1016/S0370-2693(00)01125-4
[54]	C. Moreno and O. Sarbach, Phys. Rev. D, 67: 024028 (2003) doi: 10.1103/PhysRevD.67.024028
[55]	K. K. J. Rodrigue, M. Saleh, B. B. Thomas et al, Thermodynamics Phase Transition of Regular Hayward Black hole Surrounded by Quintessence, arXiv: 1808.03474
[56]	C. H. Bayraktar, Eur. Phys. J. Plus, 133: 377 (2018) doi: 10.1140/epjp/i2018-12216-6
[57]	W. Javed, Z. Yousaf, and Z. Akhtar, Mod. Phys. Lett. A, 33: 1850089 (2018)
[58]	R. V. Maluf and J. C. S. Neves, Phys. Rev. D, 97: 104015 (2018) doi: 10.1103/PhysRevD.97.104015
[59]	M. Astorino, Phys. Rev. D, 95: 064007 (2017) doi: 10.1103/PhysRevD.95.064007
[60]	M. S. Ma and R. Zhao, Class. Quant. Grav., 31: 245014 (2014) doi: 10.1088/0264-9381/31/24/245014
[61]	M. Sharif and W. Javed, Can. J. Phys., 89: 1027-1033 (2011) doi: 10.1139/p11-089
[62]	R. Tharanath, J. Suresh, and V. C. Kuriakose, Gen. Rel. Grav., 47: 46 (2015) doi: 10.1007/s10714-015-1884-6
[63]	C. Li, C. Fang, M. He et al, Thermodynamics of the Bardeen Black Hole in Anti-de Sitter Space, arXiv: 1812.02567
[64]	A. G. Tzikas, Phys. Lett. B, 788: 219-224 (2019) doi: 10.1016/j.physletb.2018.11.036
[65]	S. Fernando, Int. J. Mod. Phys. D, 26: 1750071 (2017)
[66]	B. Z. Maytal and A. Shavit, Cryogenics, 37: 33-38 (1997) doi: 10.1016/S0011-2275(96)00094-X
[67]	R. V. Maluf and Juliano C. S. Neves, Phys. Rev. D, 97: 104015 (2018)
[68]	D. V. Singh and S. Siwach, On Thermodynamics and Statistical Entropy of Bardeen Black Hole. arXiv: 1909.11529
[69]	M. Saleh, B. B. Thomas, and T. C. Kofane, Thermodynamicsand Phase transition from regular Bardeen black hole. arXiv:1704.08302
[70]	R. Tharanath, J. Suresh, and V. C. Kuriakose, Phase transitionsand Geometrothermodynamics of Regular black holes. arXiv:1406.3916
[71]	J. Y. Man and H. B. Cheng,, Gene. Relat. Grav., 46: 1559 (2014)
[72]	S. Fernando, Int. Jour. Modern Phys. D, 07: 1750071 (2017)
[73]	T. Padmanabhan, Class. Quan. Grav., 19: 5387 (2002)
[74]	D. C. Johnston, Thermodynamic Properties of the Van derWaals Fluid. arXiv:1402.1205
[75]	L. D. Landau, E. M. Lifshitz, L. P. Pitaevski et al, Statistical physics, (1980)

References

[1]	J. D. Bekenstein, Lett. Nuovo Cimento, 4: 737-740 (1972) doi: 10.1007/BF02757029
[2]	J. D. Bekenstein, Phys. Rev. D, 7: 2333-2346 (1973)
[3]	J. M. Bardeen, B. Carter, and S. W. Hawking, Commun. Math. Phys., 31: 161-170 (1973) doi: 10.1007/BF01645742
[4]	J. D. Bekenstein, Phys. Rev. D, 9: 3292-3300 (1974)
[5]	S. W. Hawking, Nature, 248: 30-31 (1974) doi: 10.1038/248030a0
[6]	S. W. Hawking, Commun. Math. Phys., 43: 199-220 (1975), [Erratum: Commun. Math. Phys. 46: 206 (1976)]
[7]	S. W. Hawking and D. N. Page, Commun. Math. Phys., 87: 577 (1983) doi: 10.1007/BF01208266
[8]	A. Chamblin, R. Emparan, C. V. Johnson et al, Phys. Rev. D, 60: 064018 (1999) doi: 10.1103/PhysRevD.60.064018
[9]	A. Chamblin, R. Emparan, C. V. Johnson et al, Phys. Rev. D, 60: 104026 (1999) doi: 10.1103/PhysRevD.60.104026
[10]	M. Cvetic, G. W. Gibbons, D. Kubiznak et al, Phys. Rev. D, 84: 024037 (2011) doi: 10.1103/PhysRevD.84.024037
[11]	B. P. Dolan, D. Kastor, D. Kubiznak et al, Phys. Rev. D, 87: 104017 (2013) doi: 10.1103/PhysRevD.87.104017
[12]	D. Kubiznak and R. B. Mann, JHEP, 1207: 033 (2012)
[13]	D. Kastor, S. Ray, and J. Traschen, Class. Quant. Grav., 26: 195011 (2009) doi: 10.1088/0264-9381/26/19/195011
[14]	B. P. Dolan, Class. Quant. Grav., 28: 235017 (2011) doi: 10.1088/0264-9381/28/23/235017
[15]	S. Gunasekaran, R. B. Mann, and D. Kubiznak, JHEP, 1211: 110 (2012)
[16]	S. W. Wei and Y. X. Liu, Phys. Rev. D, 87: 044014 (2013) doi: 10.1103/PhysRevD.87.044014
[17]	A. Belhaj, M. Chabab, H. El Moumni et al, Chin. Phys. Lett., 30: 100401 (2012)
[18]	S. H. Hendi and M. H. Vahidinia, Phys. Rev. D, 88: 084045 (2013) doi: 10.1103/PhysRevD.88.084045
[19]	S. B. Chen, X. F. Liu, and C. Q. Liu, Chin. Phys. Lett., 30: 060401 (2013) doi: 10.1088/0256-307X/30/6/060401
[20]	E. Spallucci and A. Smailagic, Phys. Lett. B, 723: 436-441 (2013) doi: 10.1016/j.physletb.2013.05.038
[21]	R. Zhao, H. H. Zhao, M. S. Ma et al, Eur. Phys. J. C, 73: 2645 (2013) doi: 10.1140/epjc/s10052-013-2645-x
[22]	A. Belhaj, M. Chabab, H. E. Moumni et al, JHEP, 05: 149 (2015)
[23]	N. Altamirano, D. Kubiznak, and R. B. Mann, Phys. Rev. D, 88: 101502 (2013) doi: 10.1103/PhysRevD.88.101502
[24]	R. G. Cai, L. M. Cao, L. Li et al, JHEP, 1309: 005 (2013)
[25]	S. H. Hendi, and A. Dehghani, Eur. Phys. J. C, 79: 227 (2019) doi: 10.1140/epjc/s10052-019-6743-2
[26]	B. Liu, Z. Y. Yang, and R. H. Yue, Tricritical point and solid/liquid/gas phase transition of higher dimensional AdS black hole in massive gravity, arXiv: 1810.07885
[27]	S. W. Wei, P. Cheng, and Y. X. Liu, Phy. Rev. D, 93: 084015 (2016) doi: 10.1103/PhysRevD.93.084015
[28]	Z. Sun and M. S. Ma, EPL, 122: 60002 (2018) doi: 10.1209/0295-5075/122/60002
[29]	G. Miao and Z. M. Xu, Eur. Phys. J. C, 77: 403 (2017) doi: 10.1140/epjc/s10052-017-4978-3
[30]	J. Liang, C. B. Sun, and H. T. Feng, EPL, 113: 30008 (2016) doi: 10.1209/0295-5075/113/30008
[31]	J. Xu, L. M. Cao, Y. P. Hu, Phys. Rev. D, 91: 124033 (2015) doi: 10.1103/PhysRevD.91.124033
[32]	D. Kastor, S. Ray, and J. Traschen, Class. Quant. Grav., 27: 235014 (2010) doi: 10.1088/0264-9381/27/23/235014
[33]	N. Altamirano, D. Kubiznak, R. B. Mann et al, Class. Quant. Grav., 31: 042001 (2014) doi: 10.1088/0264-9381/31/4/042001
[34]	A. M. Frassino, D. Kubiznak, R. B. Mann et al, JHEP, 1409: 80 (2014)
[35]	R. A. Hennigar and R. B. Mann, Entropy, 17: 8056-8072 (2015) doi: 10.3390/e17127862
[36]	O. Ökcü and E. Aydıner, Eur. Phys. J. C, 77: 24 (2017) doi: 10.1140/epjc/s10052-017-4598-y
[37]	H. Ghaffarnejad, E. Yaraie, and M. Farsam, Int. J. Theo. Phys, 57: 1671-1682 (2018) doi: 10.1007/s10773-018-3693-7
[38]	O. Ökcü and E. Aydıner, Eur. Phys. J. C, 78: 123 (2018) doi: 10.1140/epjc/s10052-018-5602-x
[39]	J. X. Mo, G. Q. Li, S. Q. Lan et al, Phys. Rev. D, 98: 124032 (2018) doi: 10.1103/PhysRevD.98.124032
[40]	R. D’Almeida and K. P. Yogendran, Thermodynamic Properties of Holographic superfluids, arXiv: 1802.05116
[41]	M. Chabab, H. E. Moumni, S. Iraoui et al, LHEP, 2: 05 (2018)
[42]	C. L. A. Rizwan, A. N. Kumara, D. Vaid et al, Int. J. Mod. Phys., 33: 1850210 (2018) doi: 10.1142/S0217751X1850210X
[43]	J. X. Mo and G. Q. Li, Effects of Lovelock gravity on the JouleThomson expansion, arXiv: 1805.04327
[44]	S. Q. Lan, Phys. Rev. D, 98: 084014 (2018) doi: 10.1103/PhysRevD.98.084014
[45]	S. Q. Hu, Joule-Thomson expansion in AdS black holes with momentum relaxation, arXiv: 1808.07392
[46]	A. Haldar and R. Biswas, EPL., 123: 40005 (2018) doi: 10.1209/0295-5075/123/40005
[47]	Z. W. Zhao, Y. H. Xiu, and N. Li, Phys. Rev. D, 93: 124003 (2018)
[48]	A. Cisterna, S. Q. Hu, and X. M. Kuang, Joule-Thomson expansion in AdS black holes with momentum relaxation, arXiv: 1808.07392 [gr-qc]
[49]	D. M. Yekta, A. Hadikhani, and O. Ökcü, Phys. Lett. B, 795: 521-527 (2019) doi: 10.1016/j.physletb.2019.06.049
[50]	Z. W. Zhao, Y. H. Xiu, and N. Li, Phys. Rev. D, 93: 124003 (2018)
[51]	S. Q. Lan, Nucl. Phys. B, 948: 114787 (2019) doi: 10.1016/j.nuclphysb.2019.114787
[52]	J. M. Bardeen, Non-singular general-relativistic gravitational collapse, Proceedings of GR5, Tbilisi, Georgia, USSR, p. 174 (1968)
[53]	E. Ayón-Beato and A. García, Phys. Lett. B, 493: 149-152 (2000) doi: 10.1016/S0370-2693(00)01125-4
[54]	C. Moreno and O. Sarbach, Phys. Rev. D, 67: 024028 (2003) doi: 10.1103/PhysRevD.67.024028
[55]	K. K. J. Rodrigue, M. Saleh, B. B. Thomas et al, Thermodynamics Phase Transition of Regular Hayward Black hole Surrounded by Quintessence, arXiv: 1808.03474
[56]	C. H. Bayraktar, Eur. Phys. J. Plus, 133: 377 (2018) doi: 10.1140/epjp/i2018-12216-6
[57]	W. Javed, Z. Yousaf, and Z. Akhtar, Mod. Phys. Lett. A, 33: 1850089 (2018)
[58]	R. V. Maluf and J. C. S. Neves, Phys. Rev. D, 97: 104015 (2018) doi: 10.1103/PhysRevD.97.104015
[59]	M. Astorino, Phys. Rev. D, 95: 064007 (2017) doi: 10.1103/PhysRevD.95.064007
[60]	M. S. Ma and R. Zhao, Class. Quant. Grav., 31: 245014 (2014) doi: 10.1088/0264-9381/31/24/245014
[61]	M. Sharif and W. Javed, Can. J. Phys., 89: 1027-1033 (2011) doi: 10.1139/p11-089
[62]	R. Tharanath, J. Suresh, and V. C. Kuriakose, Gen. Rel. Grav., 47: 46 (2015) doi: 10.1007/s10714-015-1884-6
[63]	C. Li, C. Fang, M. He et al, Thermodynamics of the Bardeen Black Hole in Anti-de Sitter Space, arXiv: 1812.02567
[64]	A. G. Tzikas, Phys. Lett. B, 788: 219-224 (2019) doi: 10.1016/j.physletb.2018.11.036
[65]	S. Fernando, Int. J. Mod. Phys. D, 26: 1750071 (2017)
[66]	B. Z. Maytal and A. Shavit, Cryogenics, 37: 33-38 (1997) doi: 10.1016/S0011-2275(96)00094-X
[67]	R. V. Maluf and Juliano C. S. Neves, Phys. Rev. D, 97: 104015 (2018)
[68]	D. V. Singh and S. Siwach, On Thermodynamics and Statistical Entropy of Bardeen Black Hole. arXiv: 1909.11529
[69]	M. Saleh, B. B. Thomas, and T. C. Kofane, Thermodynamicsand Phase transition from regular Bardeen black hole. arXiv:1704.08302
[70]	R. Tharanath, J. Suresh, and V. C. Kuriakose, Phase transitionsand Geometrothermodynamics of Regular black holes. arXiv:1406.3916
[71]	J. Y. Man and H. B. Cheng,, Gene. Relat. Grav., 46: 1559 (2014)
[72]	S. Fernando, Int. Jour. Modern Phys. D, 07: 1750071 (2017)
[73]	T. Padmanabhan, Class. Quan. Grav., 19: 5387 (2002)
[74]	D. C. Johnston, Thermodynamic Properties of the Van derWaals Fluid. arXiv:1402.1205
[75]	L. D. Landau, E. M. Lifshitz, L. P. Pitaevski et al, Statistical physics, (1980)

[1]	Rui-Bo Wang , Shi-Jie Ma , Lei You , Jian-Bo Deng , Xian-Ru Hu . Thermodynamics of Schwarzschild-AdS black hole in non-commutative geometry. Chinese Physics C, 2025, 49(6): 065101. doi: 10.1088/1674-1137/adbacd
[2]	Meng-Yao Zhang , Hao Chen , Hassan Hassanabad , Zheng-Wen Long , Hui Yang . Critical behavior and Joule-Thomson expansion of charged AdS black holes surrounded by exotic fluid with modified Chaplygin equation of state. Chinese Physics C, 2024, 48(6): 065101. doi: 10.1088/1674-1137/ad32c0
[3]	Muhammad Yasir , Tiecheng Xia , Faisal Javed , G. Mustafa . Thermal analysis and Joule-Thomson expansion of black hole exhibiting metric-affine gravity. Chinese Physics C, 2024, 48(1): 015103. doi: 10.1088/1674-1137/ad0962
[4]	Meng-Yao Zhang , Hao Chen , Hassan Hassanabadi , Zheng-Wen Long , Hui Yang . Joule-Thomson expansion of charged dilatonic black holes. Chinese Physics C, 2023, 47(4): 045101. doi: 10.1088/1674-1137/aca958
[5]	Sen Guo , Guan-Ru Li , Guo-Ping Li . Shadow thermodynamics of an AdS black hole in regular spacetime. Chinese Physics C, 2022, 46(9): 095101. doi: 10.1088/1674-1137/ac6dc8
[6]	Shihao Bi , Minghao Du , Jun Tao , Feiyu Yao . Joule-Thomson expansion of Born-Infeld AdS black holes. Chinese Physics C, 2021, 45(2): 025109. doi: 10.1088/1674-1137/abcf23
[7]	Yuan Meng , Jin Pu , Qing-Quan Jiang . P-V criticality and Joule-Thomson expansion of charged AdS black holes in the Rastall gravity. Chinese Physics C, 2020, 44(6): 065105. doi: 10.1088/1674-1137/44/6/065105
[8]	Qi Meng , Qian Wu , Peng Cheng , Jialun Ping , Hongshi Zong . Calculation of dissociation temperature of quarkonium using Gaussian Expansion Method. Chinese Physics C, 2018, 42(8): 083103. doi: 10.1088/1674-1137/42/8/083103
[9]	Ling-Xiao Cui , Zhen Fang , Yue-Liang Wu . Finite temperature effect in infrared-improved AdS/QCD model with back reaction of bulk vacuum. Chinese Physics C, 2016, 40(6): 063101. doi: 10.1088/1674-1137/40/6/063101
[10]	Jing Wang , Jian-Long Huang , Xiao-Qi Zhang , Bin Zhang , Yuan He , Zhou-Li Zhang , Ai-Min Shi . Frequency tuning with RFQ temperature in China ADS Injector Ⅱ. Chinese Physics C, 2016, 40(3): 037003. doi: 10.1088/1674-1137/40/3/037003
[11]	WANG Zai-Jun , REN Zhong-Zhou , DONG Tie-Kuang . Probe the 2s_1/2 and 1d_3/2 state level inversion with electron-nucleus scattering. Chinese Physics C, 2014, 38(2): 024102. doi: 10.1088/1674-1137/38/2/024102
[12]	LIU Jia , KANG Zhong-Bo , WANG En-ke . Recursive method for opacity expansion at finite temperature. Chinese Physics C, 2011, 35(1): 44-49. doi: 10.1088/1674-1137/35/1/010
[13]	HAN Yi-Wen , BAO Zhi-Qing , HONG Yun . Unruh-Verlinde temperature and energy of (2+1)-dimensional matter coupled black hole via entropic force. Chinese Physics C, 2011, 35(7): 612-615. doi: 10.1088/1674-1137/35/7/003
[14]	ZHOU Xue-Mei , LIU Gui-Min , HOU Jie , ZHANG Wen-Zhi , TIAN Shun-Qiang . Excitation curve calibration for the SSRF magnet system. Chinese Physics C, 2010, 34(5): 589-592. doi: 10.1088/1674-1137/34/5/015
[15]	CHEN Zhi-Qiang , DING Fei , HUANG Zhi-Feng , ZHANG Li , YIN Hong-Xia , WANG Zhen-Chang , ZHU Pei-Ping . Polynomial curve fitting method for refraction-angle extraction in diffraction enhanced imaging. Chinese Physics C, 2009, 33(11): 969-974. doi: 10.1088/1674-1137/33/11/008
[16]	HAN Yi-Wen , HAO Jia-Bo . Non-thermal Hawking radiation from the Kerr black hole. Chinese Physics C, 2009, 33(2): 94-97. doi: 10.1088/1674-1137/33/2/003
[17]	LI Chao-Li , WANG Wei , HE Ming , WU Shao-Yong , Shen Hong-Tao , JIANG Shan , RUAN Xiang-Dong . A Bragg curve detector and its application in AMS measurements for medium-weight nuclides. Chinese Physics C, 2008, 32(S2): 210-213.
[18]	HAO Xin , ZHU Li-Hua , WU Xiao-Guang , HE Chuang-Ye , LI Guang-Sheng , LI Xue-Qin , LIU Ying , LI Li-Hua , PAN Bo . High-spin states and signature inversion studies in ¹¹⁰Ag. Chinese Physics C, 2008, 32(S2): 143-145.
[19]	Zhang Yuhu , Zhao Qingzhong , Zhou Xiaohong , Sun Xiangfu , Lei Xiangguo , Guo Yingxiang , Liu Zhong , Chen Xinfeng , Zhu Yongtai , Wen Shuxian , Yuan Guanjun , Liu Xiangan . High-Spin States in ¹⁶²Lu and Signature Inversion of Yrast Bands in Doubly Odd Nuclei Around the A=160 Mass Region. Chinese Physics C, 1997, 21(S2): 15-24.
[20]	Zheng Xite , Lei Chunhong , Li Yuliang , Chen Hong . Study of Higher Order Cumulant Expansion of U(l) Lattice Gauge Model at Finite Temperature. Chinese Physics C, 1993, 17(S3): 271-276.

Access

Cited by

1.	Javed, F., Zeeshan Gul, M., Donmez, O. et al. Joule-Thomson expansion with Barrow entropy and particle dynamics of charged Rastall-AdS black hole[J]. Nuclear Physics B, 2025. doi: 10.1016/j.nuclphysb.2025.117001
2.	Huo, T., Liu, C. Thermodynamics and the Joule-Thomson Expansion of Charged Hayward-AdS Black Hole in the Extended Phase Space[J]. International Journal of Theoretical Physics, 2025, 64(6): 173. doi: 10.1007/s10773-025-06027-0
3.	Wang, R.-B., Ma, S.-J., You, L. et al. Thermodynamics of Schwarzschild-AdS black hole in non-commutative geometry[J]. Chinese Physics C, 2025, 49(6): 065101. doi: 10.1088/1674-1137/adbacd
4.	Tan, B.. Thermodynamics of high order correction for Schwarzschild-AdS black hole in non-commutative geometry[J]. Nuclear Physics B, 2025. doi: 10.1016/j.nuclphysb.2025.116868
5.	Media, N., Singh, T.I. Joule-Thomson Expansion of Kerr-Newman-de Sitter Black Hole Under Lorentz Violation Theory[J]. International Journal of Theoretical Physics, 2025, 64(4): 82. doi: 10.1007/s10773-025-05949-z
6.	Javed, F., Waseem, A., Channuie, P. et al. Particle dynamics and Joule–Thomson expansion of phantom anti-de Sitter black hole stability and thermal fluctuations in massive gravity[J]. Physics of the Dark Universe, 2025. doi: 10.1016/j.dark.2024.101766
7.	Liu, T.-Y.. Joule-thomson expansion of vanished cooling region for five-dimensional neutral Gauss-Bonnet AdS black hole[J]. General Relativity and Gravitation, 2024, 56(11): 140. doi: 10.1007/s10714-024-03326-5
8.	Wang, R.-B., Ma, S.-J., You, L. et al. Thermodynamics of AdS-Schwarzschild-like black hole in loop quantum gravity[J]. European Physical Journal C, 2024, 84(11): 1161. doi: 10.1140/epjc/s10052-024-13505-y
9.	Abdusattar, H., Kong, S.-B. Cooling-heating properties of the FRW universe in gravity with a generalized conformal scalar field[J]. Nuclear Physics B, 2024. doi: 10.1016/j.nuclphysb.2024.116719
10.	Javed, F., Mustafa, G., Fatima, G. et al. Joule-Thomson expansion for charged-AdS black hole with nonlinear electrodynamics and thermal fluctuations by using Barrow entropy[J]. Journal of High Energy Astrophysics, 2024. doi: 10.1016/j.jheap.2024.09.003
11.	Shukla, B., Das, P.P., Dudal, D. et al. Interplay between the Lyapunov exponents and phase transitions of charged AdS black holes[J]. Physical Review D, 2024, 110(2): 024068. doi: 10.1103/PhysRevD.110.024068
12.	Malik, A., Chaudhary, S., Metwally, A.S.M. Joule–Thomson expansion and images of black hole in SU(N)-non-linear sigma model[J]. European Physical Journal C, 2024, 84(6): 610. doi: 10.1140/epjc/s10052-024-12857-9
13.	Kumar, A., Ghosh, S.G., Beesham, A. Extended phase space thermodynamics of Bardeen–Letelier black holes in 4D Einstein–Gauss–Bonnet gravity[J]. European Physical Journal Plus, 2024, 139(5): 439. doi: 10.1140/epjp/s13360-024-05235-7
14.	Ali, R.H., Abbas, G., Mustafa, G. Effect of scalar hair on magnetically charge Euler-Heisenberg AdS black hole via extended phase transition[J]. Physics of the Dark Universe, 2024. doi: 10.1016/j.dark.2024.101465
15.	Abbas, G., Ali, R.H., Mustafa, G. Thermodynamical analysis with extended phase transition of AdS hairy black hole in gravitational decoupling theory[J]. Physica Scripta, 2024, 99(4): 045025. doi: 10.1088/1402-4896/ad340a
16.	Guo, Y., Xie, H., Miao, Y.-G. Recovery of consistency in thermodynamics of regular black holes in Einstein's gravity coupled with nonlinear electrodynamics[J]. Nuclear Physics B, 2024. doi: 10.1016/j.nuclphysb.2024.116491
17.	Yasir, M., Xia, T., Javed, F. et al. Thermal analysis and Joule-Thomson expansion of black hole exhibiting metric-affine gravity[J]. Chinese Physics C, 2024, 48(1): 015103. doi: 10.1088/1674-1137/ad0962
18.	Lan, C., Yang, H., Guo, Y. et al. Regular Black Holes: A Short Topic Review[J]. International Journal of Theoretical Physics, 2023, 62(9): 202. doi: 10.1007/s10773-023-05454-1
19.	Javed, F., Fatima, G., Sadiq, S. et al. Thermodynamics of Charged Black Hole in Symmetric Teleparallel Gravity[J]. Fortschritte Der Physik, 2023, 71(6-7): 2200214. doi: 10.1002/prop.202200214
20.	Roy, T., Sardar, A., Debnath, U. Thermodynamic overview and heat engine efficiency of Kerr-Sen-AdS black hole[J]. International Journal of Geometric Methods in Modern Physics, 2023, 20(8): 2350136. doi: 10.1142/S0219887823501360
21.	Masmar, K.. Joule-Thomson expansion for a nonlinearly charged Anti-de Sitter black hole[J]. International Journal of Geometric Methods in Modern Physics, 2023, 20(5): 2350080. doi: 10.1142/S0219887823500809
22.	Li, G.-R., Guo, S., Li, G.-P. Thermodynamics of black holes in the quintessential phase space*[J]. Chinese Physics C, 2023, 47(1): 011001. doi: 10.1088/1674-1137/ac9b2b
23.	Javed, F., Basit, A., Caliskan, A. et al. Thermal fluctuations, QNMs, and emission energy of charged ADS black hole with nonlinear electrodynamics[J]. Frontiers in Astronomy and Space Sciences, 2023. doi: 10.3389/fspas.2023.1174029
24.	Feng, Y., Nie, W., Lan, X. Joule-Thomson Expansion of d-Dimensional Charged Anti-de Sitter Black Holes Surrounded by Quintessence with a Cloud of Strings Background[J]. Journal of Donghua University English Edition, 2022, 39(6): 614-620. doi: 10.19884/j.1672-5220.202110009
25.	Abdusattar, H., Kong, S.-B., You, W.-L. et al. First principle study of gravitational pressure and thermodynamic8s of FRW universe[J]. Journal of High Energy Physics, 2022, 2022(12): 168. doi: 10.1007/JHEP12(2022)168
26.	Li, G.-R., Li, G.-P., Guo, S. Phase transition grade and microstructure of AdS black holes in massive gravity[J]. Classical and Quantum Gravity, 2022, 39(19): 195011. doi: 10.1088/1361-6382/ac8c7c
27.	Li, G.-R., Guo, S., Liang, E.-W. High-order QED correction impacts on phase transition of the Euler-Heisenberg AdS black hole[J]. Physical Review D, 2022, 106(6): 064011. doi: 10.1103/PhysRevD.106.064011
28.	Guo, S., Li, G.-R., Li, G.-P. Shadow thermodynamics of an AdS black hole in regular spacetime[J]. Chinese Physics C, 2022, 46(9): 095101. doi: 10.1088/1674-1137/ac6dc8
29.	Cao, Y., Feng, H., Tao, J. et al. Black holes in a cavity: Heat engine and Joule-Thomson expansion[J]. General Relativity and Gravitation, 2022, 54(9): 105. doi: 10.1007/s10714-022-02990-9
30.	Debnath, U.. The general class of accelerating, rotating and charged Plebanski-Demianski black holes as heat engine[J]. Nuclear Physics B, 2022. doi: 10.1016/j.nuclphysb.2022.115883
31.	Feng, Q.-M., Pu, J., Jiang, Q.-Q. Effects of magnetic monopole charge on Joule-Thomson expansion of regular Ayón Beato-García black hole[J]. Classical and Quantum Gravity, 2022, 39(15): 155007. doi: 10.1088/1361-6382/ac7b07
32.	Ditta, A., Tiecheng, X., Mustafa, G. et al. Thermal stability with emission energy and Joule–Thomson expansion of regular BTZ-like black hole[J]. European Physical Journal C, 2022, 82(8): 756. doi: 10.1140/epjc/s10052-022-10708-z
33.	Guo, Y., Miao, Y.-G. Weinhold geometry and thermodynamics of Bardeen AdS black holes[J]. Nuclear Physics B, 2022. doi: 10.1016/j.nuclphysb.2022.115839
34.	Shahzad, M.U., Nosheen, L. Some remarks on criticality and thermodynamics of the dynamic phantom AdS black holes[J]. European Physical Journal C, 2022, 82(5): 470. doi: 10.1140/epjc/s10052-022-10425-7
35.	Zhang, C.-M., Zhang, M., Zou, D.-C. Joule-Thomson expansion of Born-Infeld AdS black holes in consistent 4D Einstein-Gauss-Bonnet gravity[J]. Modern Physics Letters A, 2022, 37(11): 2250063. doi: 10.1142/S0217732322500638
36.	Jawad, A., Tasleem, M., Rani, S. Consequences of Barrow entropy on thermodynamics of charged AdS black hole and heat engine[J]. Modern Physics Letters A, 2022, 37(11): 2250062. doi: 10.1142/S0217732322500626
37.	Guo, S., Huang, Y.-L., Liang, E.-W. Comparison of thermodynamic behaviors of two regular-AdS black holes[J]. Communications in Theoretical Physics, 2022, 74(2): 025402. doi: 10.1088/1572-9494/ac41c8
38.	Liang, J., Mu, B., Wang, P. Joule-Thomson expansion of lower-dimensional black holes[J]. Physical Review D, 2021, 104(12): 124003. doi: 10.1103/PhysRevD.104.124003
39.	Zarepour, S.. Holographic Joule-Thomson expansion in lower dimensions[J]. Physica Scripta, 2021, 96(12): 125011. doi: 10.1088/1402-4896/ac2b49
40.	Biswas, A.. Joule-Thomson expansion of AdS black holes in Einstein Power-Yang-mills gravity[J]. Physica Scripta, 2021, 96(12): 125310. doi: 10.1088/1402-4896/ac2b42
41.	Yin, R., Liang, J., Mu, B. Joule–Thomson expansion of Reissner–Nordström-Anti-de Sitter black holes with cloud of strings and quintessence[J]. Physics of the Dark Universe, 2021. doi: 10.1016/j.dark.2021.100884
42.	Cao, Y., Feng, H., Hong, W. et al. Joule-Thomson expansion of RN-AdS black hole immersed in perfect fluid dark matter[J]. Communications in Theoretical Physics, 2021, 73(9): 095403. doi: 10.1088/1572-9494/ac1066
43.	Meng, Y., Chen, B.B., Tang, J. Cooling-heating phase transition of the Euler-Heisenberg-AdS black hole[J]. Modern Physics Letters A, 2021, 36(23): 2150165. doi: 10.1142/S0217732321501650
44.	Guo, S., Liang, E.-W. Ehrenfest's scheme and microstructure for regular-AdS black hole in the extended phase space[J]. Classical and Quantum Gravity, 2021, 38(12): 125001. doi: 10.1088/1361-6382/abf9b6
45.	Guo, S., Huang, Y.L., He, K.J. et al. Hayward black hole heat engine efficiency in anti-de Sitter space[J]. Modern Physics Letters A, 2021, 36(16): 2150108. doi: 10.1142/S021773232150108X
46.	Singh, B.K., Singh, R.P., Singh, D.V. P- v criticality, phase structure and extended thermodynamics of AdS ABG black holes[J]. European Physical Journal Plus, 2021, 136(5): 575. doi: 10.1140/epjp/s13360-021-01562-1
47.	Mirza, B., Naeimipour, F., Tavakoli, M. Joule-Thomson Expansion of the Quasitopological Black Holes[J]. Frontiers in Physics, 2021. doi: 10.3389/fphy.2021.628727
48.	Feng, Z.-W., Zhou, X., He, G. et al. Joule-Thomson expansion of higher dimensional nonlinearly AdS black hole with power Maxwell invariant source[J]. Communications in Theoretical Physics, 2021, 73(6): 065401. doi: 10.1088/1572-9494/abecd9
49.	Bi, S., Du, M., Tao, J. et al. Joule-Thomson expansion of Born-Infeld AdS black holes[J]. Chinese Physics C, 2021, 45(2): 025109. doi: 10.1088/1674-1137/abcf23
50.	Liu, T.-P., Pu, J., Han, Y. et al. A possible thermodynamic origin of the spacetime minimum length[J]. International Journal of Modern Physics D, 2020, 29(14): 2043022. doi: 10.1142/S0218271820430221
51.	Singh, D.V., Siwach, S. Thermodynamics and P-v criticality of Bardeen-AdS black hole in 4D Einstein-Gauss-Bonnet gravity[J]. Physics Letters Section B Nuclear Elementary Particle and High Energy Physics, 2020. doi: 10.1016/j.physletb.2020.135658
52.	Meng, Y., Pu, J., Jiang, Q.-Q. P-V criticality and Joule-Thomson expansion of charged AdS black holes in the Rastall gravity[J]. Chinese Physics C, 2020, 44(6): 065105. doi: 10.1088/1674-1137/44/6/065105

Figures(3) / Tables(1)

Get Citation

Sen Guo, Jin Pu, Qing-Quan Jiang and Xiao-Tao Zu. Joule-Thomson expansion of the regular(Bardeen)-AdS black hole[J]. Chinese Physics C, 2020, 44(3): 035102. doi: 10.1088/1674-1137/44/3/035102

Sen Guo, Jin Pu, Qing-Quan Jiang and Xiao-Tao Zu. Joule-Thomson expansion of the regular(Bardeen)-AdS black hole[J]. Chinese Physics C, 2020, 44(3): 035102. doi: 10.1088/1674-1137/44/3/035102 shu

RIS(for EndNote,Reference Manager,ProCite)

BibTex

Txt

Milestone

Received: 2019-07-19
Revised: 2019-12-24

Article Metric

Article Views(2713)
PDF Downloads(56)
Cited by(52)

Policy on re-use

To reuse of subscription content published by CPC, the users need to request permission from CPC, unless the content was published under an Open Access license which automatically permits that type of reuse.

通讯作者: 陈斌, bchen63@163.com

1.
沈阳化工大学材料科学与工程学院沈阳 110142

HTML

2. Thermodynamics of the Bardeen-AdS black hole

4. Conclusions and discussion

In this paper, we investigated the Joule-Thomson expansion of the Bardeen-AdS black hole in the extended phase space, where the cosmological constant is viewed as pressure and the black hole mass as enthalpy. We first reviewed the thermodynamic properties of the Bardeen-AdS black hole in the extended phase space and obtained its equation-of-state. We then plotted for the Joule-Thomson expansion of the Van der Waals fluid, the inversion curves and determined the cooling and heating regions in the $T-P$ plane. We also investigated the Joule-Thomson expansion of the Bardeen-AdS black hole, and plotted the related inversion curves. In contrast to the Van der Waals fluid, the inversion curves for the Bardeen-AdS black hole are not closed, and there only exists a lower inversion curve. In addition, we have plotted the inversion and isenthalpic curves for the Bardeen-AdS black hole in the $T-P$ plane, and determined the cooling and heating regions for various values of charge q and mass M. It was shown that the isenthalpic curves have positive slope above the inversion curves where cooling occurs, while the sign of the slope is negative below the inversion curves where heating occurs.

The ratio between the minimum inversion temperature and critical temperature for the Bardeen-AdS black hole is smaller than for the Van der Waals fluid (0.75), but is larger than any known ratio for the singular black hole. The large ratio is universal for the regular black hole, in contrast to the singular black hole, and it should therefore be related to a specific property of the regular black hole. In fact, for large distances ( $r\gg q$ ), the Bardeen-AdS black hole coincides with the conventional Schwarzschild-AdS black hole with $f(r)\approx 1-\frac{2M}{r}+\frac{r^2}{l^2}$ . Near the origin ( $r\ll q$ ), the Bardeen-AdS black hole could be described by a line element where $f(r)\approx 1-\Big(\frac{2Ml^2}{q^3}-1\Big)\frac{r^2}{l^2}$ . According to the metric potential, the origin can be seen as: i) a repulsive de Sitter core when $2Ml^2>q^3$ ; ii) an attractive Anti de Sitter core when $2Ml^2<q^3$ ; iii) a local Minkowski core with no gravitational interaction when $2Ml^2 = q^3$ . Obviously, when the origin is an attractive Anti de Sitter core or a local Minkowski core, there is no horizon. Therefore, the Bardeen-AdS black hole exists only in the case of a repulsive de Sitter core at the origin. There is in any case a repulsive de Sitter core in a regular(Bardeen)-AdS black hole, in contrast to the singular black hole. Thus, we conclude that the large ratio for the regular(Bardeen)-AdS black hole may be due to the repulsive de Sitter core near the origin of the regular black hole. On the other hand, for the Van der Waals fluid, there exists a repulsive volume, in contrast to the ideal fluid, and studies have shown that in this case the ratio between the minimum inversion temperature and critical temperature is always larger than for the singular black hole. Therefore, it is reasonable to assume that a repulsive de Sitter core near the origin of the regular(Bardeen)-AdS black hole leads to the large ratio of these temperatures.

After we have completed this paper, a similar study appeared in arXiv:1904.09548.

Reference (75)

Joule-Thomson expansion of the regular(Bardeen)-AdS black hole

Abstract：

1. Introduction

1. Introduction
2. Thermodynamics of the Bardeen-AdS black hole
3. The Joule-Thomson expansion
3.1 The Van der Waals fluid
3.2 The Bardeen-AdS black hole
4. Conclusions and discussion

2. Thermodynamics of the Bardeen-AdS black hole

1. Introduction
2. Thermodynamics of the Bardeen-AdS black hole
3. The Joule-Thomson expansion
3.1 The Van der Waals fluid
3.2 The Bardeen-AdS black hole
4. Conclusions and discussion

3. The Joule-Thomson expansion

1. Introduction
2. Thermodynamics of the Bardeen-AdS black hole
3. The Joule-Thomson expansion
3.1 The Van der Waals fluid
3.2 The Bardeen-AdS black hole
4. Conclusions and discussion

3.1 The Van der Waals fluid

1. Introduction
2. Thermodynamics of the Bardeen-AdS black hole
3. The Joule-Thomson expansion
3.1 The Van der Waals fluid
3.2 The Bardeen-AdS black hole
4. Conclusions and discussion

Figure 1

3.2 The Bardeen-AdS black hole

1. Introduction
2. Thermodynamics of the Bardeen-AdS black hole
3. The Joule-Thomson expansion
3.1 The Van der Waals fluid
3.2 The Bardeen-AdS black hole
4. Conclusions and discussion

Figure 2

Figure 3

Table 1

4. Conclusions and discussion

1. Introduction
2. Thermodynamics of the Bardeen-AdS black hole
3. The Joule-Thomson expansion
3.1 The Van der Waals fluid
3.2 The Bardeen-AdS black hole
4. Conclusions and discussion

References

References

Access

Cited by

Article Metrics

Metrics

通讯作者: 陈斌, bchen63@163.com

Email This Article
