Classical novae are believed to be closed binary systems comprising a white dwarf and a main sequence or red giant star. When the distance between the stars is below the Roche limit, the white dwarf in the system accretes the H-rich matter from its companion. A classical nova outburst takes place upon occurrence of a thermonuclear runaway (TNR), driven by compression of the H-rich matter [1]. Approximately 25–30% of the novae are of the ONe type containing massive ONe dwarfs [2]. Observations of Ne lines [3] demonstrate the enrichment of Ne in Neon novae. The NeNa and the MgAl cycles start to produce heavier nuclei after the breakout of the hot CNO cycles, as preexisting 20Ne nuclei are present [4–7]. Novae observations provide evidence of productions of elements, such as Si and P [8]. Furthermore, the Ne-E meteoritic neon component enriched in 22Ne may also originate from the novae [2, 9].
22Na and 26Al are long-lived isotopes that may be observed as
γ -ray sources by detectors if they do not participate in any reactions before ejection [5, 10]. 22Na, whose half-life is 2.602 y,β+ -decays to the first excited state in 22Ne, and subsequently de-excites with the emission of an accompanying 1.275 MeVγ -ray [11]. Detections of the 1.275 MeVγ -ray from a classical nova outburst found little evidence of the 1.275 MeV line and only provided upper limits of the ejected 22Na, either by the SMM [12] or the COMPTEL and OSSE instruments onboard the CGRO [13-16]. Several nuclear reaction network studies have predicted the ejected abundances of 22Na in novae [17-20]; however, a large uncertainty still remains [7, 21]. Moreover, some theoretical estimations yielded abundances significantly higher than the upper limits obtained by observation [15, 22].22Na is mainly produced via a reaction chain,20Ne(p,γ)21Na(p,γ)22Mg(β+ν)22Na [4–7]. While the proton capture reaction22Na(p,γ)23Mg is considered as the main approach of the destruction of 22Na [23, 24],22Mg(p,γ)23Al may also deplete22Mg on the reaction chain according to the temperature and density conditions [25]. Thus far, there has been no direct measurement of the reaction, mainly because of the unstable isotope22Mg with the half-life of 3.88 s [11] involved in the entrance channel. To date, the22Mg(p,γ)23Al reaction was studied using a few indirect methods. The excitation energy of the first excited state in 23Al was observed by the 24Mg(7Li,8He ) 23Al reaction to be (460±60 ) keV for the first time [25] and (550±20 ) keV in a more accurate measurement [26]. Resonant and direct capture rates were deduced from the excitation energy values together with spectroscopic factors from shell-model calculations [25, 26]. Simplified network calculations revealed that proton capture rates of 22Mg at those magnitudes only lead to limited 23Al and 24Si production [26]. The gamma width of the first excited state in 23Al was determined to be7.2×10−7 eV using the coulomb-dissociation method in RIKEN [27, 28]. The spin and parity of the 23Al ground state was found to beJΠ=5/2+ by independent measurements [29, 30]. New states in 23Al were observed, and the reaction rates were reevaluated [31], adopting the experimental value of the gamma width in Ref. [28]. As for the direct capture contribution, the proton asymptotic normalization coefficient (ANC) for the 23Al ground state was experimentally found to beC2d5/2(23Al)=(4.63±0.77)× 103fm−1 from the13C(22Ne,23Ne)12C transfer reaction in the mirror nuclear system [32] andC2d5/2(23Al)= (3.90±0.44)×103fm−1 from the one-proton breakup reaction of 23Al [33]. The measurement with a new transfer reaction will be helpful to independently verify the former ANCs.In this study, we aim to determine the astrophysical S-factors and stellar rates of the
22Mg(p,γ)23Al reaction from the previous experimental angular distributions of22Ne(d,p)23Ne [34, 35] based on the mirror symmetry of a strong interaction. The relationships between the neutron and proton ANCs or width in mirror nuclear systems were previously established by Timofeyuk et al. [36], and have been successfully applied in several studies [37-39]. The neutron ANCs of23Ne→22Ne+n for the ground state and the first excited state are derived from the angular distributions of22Ne(d,p)23Ne within the frame of the adiabatic distorted wave approximation (ADWA) [40] and continuum discretized coupled channel (CDCC) analysis [41]. The adiabatic approximation for the(d,p) reactions was systematically investigated by Chazono et al. [42]. In comparison with other incident particles, the deuteron exhibits a simpler structure that is better understood.We discuss the neutron ANCs for
23Ne→22Ne+n in Section 2 and the proton ANC and width of the 23Al ground state and the first excited state, respectively, in Section 3. The astrophysical S-factors and reaction rates are presented in Section 4. The conclusion is provided in Section 5. -
In the case of peripheral transfer reactions, the neutron ANCs for the virtual decay of
23Ne→22Ne+n can be obtained by(dσdΩ)exp=C2liji(d)C2lfjf(23Ne)σthlijilfjfb2liji(d)b2lfjf(23Ne),
(1) where
(dσdΩ)exp andσthlijilfjf are the experimental and theoretical differential cross-sections, respectively,C2liji(d) andC2lfjf(23Ne) are the ANCs ford→p+n and23Ne→22Ne+n , respectively, andb2liji(d) andb2lfjf(23Ne) are the single-particle ANCs of the deuteron and23Ne , respectively. The experimental angular distributions are assumed from Refs. [34, 35].The FRESCO code [43] was used to calculate theoretical angular distributions. The optical potential parameters of the entrance channel were obtained from the neutron-target and proton-target optical potentials within the adiabatic approximation [40], considering the breakup effects of the deuteron. Additionally, the CDCC calculations [41] were also performed to understand the uncertainty from the reaction models by comparison with the ADWA results. The continuum states were discretized up to
kmax=1fm−1 , with a step size ofΔk=0.05fm−1 . The exit channel parameters are the proton-target optical potential parameters at the corresponding outgoing energy.C2s1/2(d) assumes the value of 0.76 fm-1 from Ref. [44]. The nucleon-target potential parameters were provided by Varner et al. [45] and Koning et al. [46], as listed in Table 1.Method Channel Potential V r0 a VSI rSI0 aSI VI rI0 aI VSO rSO0 aSO rC0 ADWA d+22 NeVarner 96.64 1.17 0.72 14.03 1.18 0.69 1.82 1.55 0.46 5.90 0.91 0.63 1.28 Koning 99.42 1.16 0.71 14.46 1.30 0.57 0.97 1.55 0.46 5.66 0.95 0.57 1.36 p+23 NeVarner 51.64 1.17 0.69 8.26 1.18 0.69 1.35 1.18 0.69 5.90 0.92 0.63 1.28 Koning 53.77 1.16 0.67 8.77 1.30 0.53 1.25 1.16 0.67 5.47 0.96 0.59 1.35 CDCC p+22 NeVarner 53.72 1.17 0.69 8.37 1.18 0.69 0.84 1.18 0.69 5.90 0.91 0.63 1.28 Koning 56.58 1.16 0.68 7.72 1.30 0.53 0.51 1.16 0.68 5.66 0.95 0.59 1.36 n+22 NeVarner 49.90 1.17 0.69 5.79 1.18 0.69 1.10 1.18 0.69 5.90 0.91 0.63 1.28 Koning 50.32 1.16 0.68 6.86 1.30 0.54 0.59 1.16 0.68 5.60 0.95 0.59 1.36 p+23 NeVarner 51.64 1.17 0.69 8.26 1.18 0.69 1.35 1.18 0.69 5.90 0.92 0.63 1.28 Koning 53.77 1.16 0.67 8.77 1.30 0.53 1.25 1.16 0.67 5.47 0.96 0.59 1.35 Table 1. Entrance and exit optical potential parameters, where
Vi are in MeV,ri0 andai are in units of fm. If i represents null, the parameters will be real volume-central potentials.SI depicts imaginary surface-central potentials, I depicts imaginary volume-central potentials,SO depicts real spin-orbit potentials, and C depicts the Coulomb potential.The neutron ANCs were extracted by normalization of the present ADWA and CDCC calculations to the experimental angular distributions via Eq. (1). The discrepancies between the ADWA and CDCC results were found to be 9% and 13% for the ANCs of the ground state and the first excited state, which is in agreement with the conclusion of the previous systematic study by Chazono et al. [42]. Figure 1 shows the normalized angular distributions of the
22Ne(d,p)23Ne reaction, leading to the ground and first excited states of 23Ne with the ADWA and CDCC approaches, together with the experimental data [34, 35]. Furthermore, the peripherality of the reaction should be ensured when the ANC method is adopted. The dependence of both the spectroscopic factors and the square of the ANCs on the radius of the binding potential is calculated, as shown in Fig. 2. The spectroscopic factors vary considerably, whereas the neutron ANCs are more stable, which indicates the peripherality of this reaction at the present energy. The uncertainties of 2% and 5% were derived for the ANCs of the ground state and the first excited state, respectively.Figure 1. (color online) Experimental and theoretical
22Ne(d,p)23Ne differential cross-sections for the ground state and first excited state of23Ne with an incident energy of 12.1 MeV. The red dots and black squares refer to the experimental angular distributions from Lutz et al. [34] and Howard et al. [35], respectively. The curves denote the present ADWA and CDCC calculations with the OMP parameters listed in Table 1.The square of the ANCs
C2d5/2(23Ne)=(0.483±0.060) fm-1 andC2s1/2(23Ne)=(9.7±2.3)fm−1 . The uncertainty arises from the statistics (4% for the ground state and 18% for the first excited state), different sets of the experimental data (1% for the ground state), two sets of optical model potentials (7% for both states), discrepancy between the ADWA and CDCC methods (9% for the ground state and 13% for the first excited state), and breakdown of peripherality (2% for the ground state and 5% for the first excited state).In Table 2, we list the present ANCs of 23Ne along with the previous results. The new neutron ANCs for the ground and first excited states are smaller than those from the (13C, 12C) reaction by a factor of ~2 [32].
Ex /MeVJπ ANC2/fm−1 (13C, 12C)[32] Present 0 5/2+ 0.86±0.14 0.483±0.060 1.017 1/2+ 18.2±4.2 9.7±2.3 Table 2. Present ANCs of 23Ne in comparison with previous experimental results.
-
The ground states of
23Al and23Ne are mirror pairs. The proton ANC of23Alg.s. can be extracted from the neutron ANC of23Neg.s. as a result of charge symmetry. The spin and parity of23Alg.s. were measured to be5/2+ [30, 33], which is the same as its mirror nucleus. The relationship is described asC2d5/2(23Al)=R∗C2d5/2(23Ne),
(2) where R is the ratio.
The relationship of the ANCs for mirror pairs was established as [36, 47]
R=|Fl(ikpRN)kpRNjl(iknRN)|2,
(3) where
Fl is the regular Coulomb wave function,jl is the Bessel function,RN is the radius of the nuclear interior, andkp andkn are the wave numbers of the proton and neutron related to the separation energies, respectively. The ratio R was derived to be 5,440 whenRN=1.3×A1/3 fm. Furthermore, we investigated the dependence of R onRN by changing theRN values from1.1×A1/3 to1.5×A1/3 fm, and found that the deviation was less than 1%.In contrast, based on the assumption that the difference in the spectroscopic factors for the mirror pairs can be ignored, R can also be obtained by
R=b2d5/2(23Al)b2d5/2(23Ne),
(4) where
b2d5/2(23Al) andb2d5/2(23Ne) refer to the respective single-particle ANCs. The single-particle ANCs were calculated with the same geometry parametersr0 and a, and the same spin-orbit interaction. The depth of the central potential was adjusted to reproduce the latest experimental proton binding energy 0.143 MeV in23Al [30].The ratios inferred from Eq. (3) and Eq. (4) were
5.44×103 and5.47×103 , respectively. The average was used for the following calculation, and their difference was included in the total uncertainty. The proton ANC of23Alg.s. was found to beC2d5/2(23Al)=(2.65±0.33)×103 fm−1. In Table 3, we list the present proton ANCs of 23Al along with the previous results. The present proton ANC is significantly smaller than the previous experimental value of(4.63±0.77)×103fm−1 from the (13C,12C) reaction [32]. This is because the present neutron ANC of 23Ne from the (d,p ) reaction is approximately half that from the (13C, 12C) reaction.Table 3. Present ANC or width of 23Al in comparison with previous experimental results.
Regarding the first excited state of
23Al , the proton widthΓp of the resonance can also be deduced from the neutron ANC of its mirror state in23Ne byΓp=Rres∗C2s1/2(23Ne),
(5) where
Rres is given by both [36, 48]Rres=ℏ2kpμ|Fl(kpRN)kpRNjl(iknRN)|2
(6) and
Rres=Γsppb2s1/2(23Ne),
(7) where
Γspp represents the single particle width. The average of the ratios from Eq. (6) and Eq. (7) was used to calculate the proton width of the23Al first excited state, which was determined to beΓp=(57±14) eV. The new width is in approximate agreement with the value of (32±5 ) eV from the measurement of the resonant proton scattering of 22Mg+p by He et al. [31]. -
The ANC can describe the tail of the overlap function of the bound state wave functions of the projectile, target, and residual nucleus. Then, the cross-section of the peripheral direct capture can be determined along with the scattering wave function in the entrance channel [49].
The RADCAP code [50] was utilized to calculate the cross-section and the astrophysical S-factor of the direct capture reaction. The depth of the proton binding potential was adjusted to reproduce the binding energy
0.143 MeV [30], with the same geometry parametersr0 and a as the ones used when calculating the neutron ANC of23Neg.s. . This direct capture reaction is mainly dominated by the E1 transition from the incoming p wave at low energies of astrophysical interest. The S-factors for direct capture are shown in Fig. 3. The direct S-factor at zero energy was found to beSdir(0)=(0.53±0.07) keV b, whereas the values in previous studies were(0.96±0.11) keV b [32] and(0.73±0.10) keV b [33]. The difference was mainly caused by different ANCs.Figure 3. (color online) Astrophysical S-factors of
22Mg(p,γ)23Al direct capture (red solid curve) and resonant capture through the first excited state of23Al (black dashed curve) at different center-of-mass energies.The S-factor of the resonance through the
1/2+ state of23Al can be deduced by the Breit–Wigner formula [51, 52]Sres(E)=πℏ22μ2J+1(2J1+1)(2J2+1)×Γp(E)Γγ(E)(E−ER)2+(Γtot/2)2exp(EGE)1/2,
(8) where J,
J1 , andJ2 depict the spins of23Al , the proton, and22Mg , respectively;Γp ,Γγ andΓtot represent the proton, gamma, and total widths, respectively;ER andEG depict the resonance and Gamow energies, respectively. The energy dependence of the widths is given by [53, 54]Γp(E)=Γp(ER)exp[−(EG/E)1/2]exp[−(EG/ER)1/2]
(9) and
Γγ(E)=Γγ(ER)(Q+E)2l+1(Q+ER)2l+1,
(10) where Q represents the reaction Q value, and l represents the multipolarity of the gamma transition. The
Sres factors are also shown in Fig. 3. This resonance was dominated by theE2 transition, and thus does not interfere with the direct capture dominated by theE1 transition.The reaction rate of the capture reactions can be integrated by
NA<σv>=NA(8πμ)1/2(1kT)3/2×∫∞0S(E)exp(−EkT−(EGE)1/2)dE,
(11) where
NA and k refer to Avogadro's and Boltzmann's constant,μ is the reduced mass, and T is the temperature.The reaction rates of the direct and resonant captures at different temperatures are shown in Fig. 4. The result shows that the direct capture dominates the
22Mg(p,γ)23Al reaction at most temperatures of astrophysical relevance within the range0.33<T9<0.64 . The present numerical rates are listed in Table 4, along with the previous results. The differences with respect to other studies are mainly due to different values of the proton ANC of23Alg.s. adopted, as discussed in Sections 2 and 3.Figure 4. (color online) Direct capture (red solid curve), resonant capture through first excited state of
23Al (black dashed curve), and total (blue dotted curve) astrophysical reaction rates of22Mg(p,γ)23Al as a function of temperature.Present Wiescher et al. [25] Caggiano et al. [26] He et al. [31] Al-Abdullah et al. [32] T9 NA<σv> /(cm3/mol s)NA<σv> /(cm3/mol s)ratio NA<σv> /(cm3/mol s)ratio NA<σv> /(cm3/mol s)ratio NA<σv> /(cm3/mol s)ratio 0.10 1.38×10−13 5.03×10−14 0.36 1.70×10−13 1.23 1.67×10−13 1.21 2.62×10−13 1.90 0.20 1.63×10−9 5.70×10−10 0.35 1.89×10−9 1.16 1.96×10−9 1.20 3.19×10−9 1.96 0.30 2.45×10−7 8.42×10−8 0.34 2.08×10−7 0.85 2.83×10−7 1.15 5.14×10−7 2.10 0.40 5.87×10−6 2.00×10−6 0.34 4.42×10−6 0.75 6.58×10−6 1.12 1.12×10−5 1.91 0.50 4.43×10−5 1.50×10−5 0.34 3.43×10−5 0.77 4.49×10−5 1.01 7.94×10−5 1.79 0.60 1.80×10−4 5.98×10−5 0.33 1.49×10−4 0.83 2.03×10−4 1.12 3.15×10−4 1.75 0.70 5.23×10−4 1.69×10−4 0.32 4.58×10−4 0.88 5.94×10−4 1.14 9.17×10−4 1.75 0.80 1.24×10−3 3.88×10−4 0.31 1.14×10−3 0.92 1.43×10−3 1.15 2.23×10−3 1.80 0.90 2.59×10−3 7.85×10−4 0.30 2.48×10−3 0.96 3.03×10−3 1.17 4.83×10−3 1.86 1.00 4.95×10−3 1.45×10−3 0.29 4.86×10−3 0.98 5.86×10−3 1.18 9.58×10−3 1.94 1.50 5.54×10−2 1.42×10−2 0.26 5.41×10−2 0.98 6.85×10−2 1.24 1.27×10−1 2.29 2.00 2.62×10−1 6.45×10−2 0.25 2.54×10−1 0.97 3.50×10−1 1.34 7.24×10−1 2.77 Table 4. Total astrophysical reaction rates of
22Mg(p,γ)23Al capture reaction in comparison with previous results.With REACLIB's standard formula [55, 56], the total reaction rate is fitted as
NA<σv>=exp[3.65959−0.00604581T−19−24.0405T−1/39+17.244T1/39−2.48044T9+0.181537T5/39−4.69873ln(T9)]+exp[115.723+3.46144T−19−267.374T−1/39+97.5552T1/39+68.1136T9−24.9189T5/39−144.28ln(T9)],
(12) with fitting errors being less than 5% at the temperatures from 0.02 GK to 10 GK. The present rate with this formula can be conveniently used in stellar modeling.
In the nova models adopted in Ref. [21], the peak temperatures range from 0.145 GK to 0.418 GK. If the proton capture dominates over the
β -decay of 22Mg, the required hydrogen density values at those typical peak temperatures are larger than the corresponding peak densityvalues in the models by at least one order of magnitude. -
We extracted the neutron ANCs for the ground state and the first excited state of 23Ne from the experimental differential cross-sections of the
22Ne(d,p)23Ne reaction through the ADWA and CDCC analysis. Then, the proton ANC for the ground state and the proton width of the first excited state of23Al were deduced according to the charge symmetry of the mirror nuclei. The astrophysical S-factors and reaction rates of the direct capture to the ground state and the resonant capture to the first excited state in the22Mg(p,γ)23Al reaction were extracted from the present ANC and proton width. The present total reaction rates are approximately half that of the most recent values obtained from the measurement of the (13C, 12C) reaction [32]. This is because the present neutron ANC of 23Ne from the (d,p ) reaction is approximately half that from the (13C, 12C) reaction. It is highly desirable to understand such a large difference between the results from the (d,p ) reaction and the (13C, 12C) reaction in the future. Our result supports the claim that the direct capture dominates the22Mg(p,γ)23Al reaction at most astrophysical temperatures.
Method | Channel | Potential | V | ![]() | a | ![]() | ![]() | ![]() | ![]() | ![]() | ![]() | ![]() | ![]() | ![]() | ![]() |
ADWA | ![]() | Varner | 96.64 | 1.17 | 0.72 | 14.03 | 1.18 | 0.69 | 1.82 | 1.55 | 0.46 | 5.90 | 0.91 | 0.63 | 1.28 |
Koning | 99.42 | 1.16 | 0.71 | 14.46 | 1.30 | 0.57 | 0.97 | 1.55 | 0.46 | 5.66 | 0.95 | 0.57 | 1.36 | ||
![]() | Varner | 51.64 | 1.17 | 0.69 | 8.26 | 1.18 | 0.69 | 1.35 | 1.18 | 0.69 | 5.90 | 0.92 | 0.63 | 1.28 | |
Koning | 53.77 | 1.16 | 0.67 | 8.77 | 1.30 | 0.53 | 1.25 | 1.16 | 0.67 | 5.47 | 0.96 | 0.59 | 1.35 | ||
CDCC | ![]() | Varner | 53.72 | 1.17 | 0.69 | 8.37 | 1.18 | 0.69 | 0.84 | 1.18 | 0.69 | 5.90 | 0.91 | 0.63 | 1.28 |
Koning | 56.58 | 1.16 | 0.68 | 7.72 | 1.30 | 0.53 | 0.51 | 1.16 | 0.68 | 5.66 | 0.95 | 0.59 | 1.36 | ||
![]() | Varner | 49.90 | 1.17 | 0.69 | 5.79 | 1.18 | 0.69 | 1.10 | 1.18 | 0.69 | 5.90 | 0.91 | 0.63 | 1.28 | |
Koning | 50.32 | 1.16 | 0.68 | 6.86 | 1.30 | 0.54 | 0.59 | 1.16 | 0.68 | 5.60 | 0.95 | 0.59 | 1.36 | ||
![]() | Varner | 51.64 | 1.17 | 0.69 | 8.26 | 1.18 | 0.69 | 1.35 | 1.18 | 0.69 | 5.90 | 0.92 | 0.63 | 1.28 | |
Koning | 53.77 | 1.16 | 0.67 | 8.77 | 1.30 | 0.53 | 1.25 | 1.16 | 0.67 | 5.47 | 0.96 | 0.59 | 1.35 |
