Scalar leptoquark and vector-like quark extended models as the explanation of the muon g–2 anomaly: bottom partner chiral enhancement case

I. INTRODUCTION

• I. INTRODUCTION
• II. MODEL SETUP
•      A VLQ Yukawa interactions with Higgs
•      B VLQ gauge interactions
•      C VLQ Yukawa interactions with LQ
• III. CONTRIBUTIONS TO $\boldsymbol{(g-2)_{\mu}}$
•      A Analytical results of contributions
•      B Numerical analysis
• IV. LQ AND VLQ PHENOMENOLOGY AT HADRON COLLIDERS
• V. SUMMARY AND CONCLUSIONS
• APPENDIX A: LQ DECAY WIDTH FORMULAE
• APPENDIX B: VLQ DECAY WIDTH FORMULAE

The $(g-2)_{\mu}$ anomaly is a longstanding puzzle in the standard model (SM) of elementary particle physics. It was first announced by the BNL E821 experiment [1]. Last year, the FNAL muon $g-2$ experiment revealed increased deviation from the SM prediction [2]. When combining the BNL and FNAL data, the averaged result is $a_{\mu}^{ \mathrm{Exp}}=116592061(41)\times10^{-11}$. Compared to the SM prediction $a_{\mu}^{ \mathrm{SM}}=116591810(43)\times10^{-11}$ [3−23], the deviation is $\Delta a_{\mu}\equiv a_{\mu}^{ \mathrm{Exp}}-a_{\mu}^{ \mathrm{SM}}=(251\pm59)\times10^{-11}$, which shows a $4.2\sigma$ discrepancy. Many new physics models were proposed to explain the anomaly [24−29].

For the mediators with mass above the TeV level, the chiral enhancements are required, which can appear when left-handed and right-handed muons couple to a heavy fermion simultaneously. In the new lepton extended models [30−33], the chiral enhancements originate from the large lepton mass. The LQ models are an alternative choice [34−40], in which the chiral enhancements originate from the large quark mass. For the minimal LQ models, there are scalar LQs $R_2/S_1$ with top quark chiral enhancement and vector LQs $V_2/U_1$ with bottom quark chiral enhancement. The LQ can connect the lepton sector and quark sector. On the other hand, the VLQ naturally occurs in many new physics models and is free of quantum anomaly. It can mix with SM quarks and provide new source of CP violation. Hence, the LQ and VLQ extended models can lead to interesting flavour physics in both the lepton sector and quark sector. In our previous study [41], we investigated the scalar LQ and VLQ ¹ extended models with top and top partner chiral enhancements. In this study, we investigate the scalar LQ and VLQ extended models, which can produce the bottom partner chiral enhancements. This paper is complementary to our previous paper [41]. Moreover, the top partner and bottom partner lead to different collider signatures.

In Sec. II, we introduce the models and show the related interactions. Then, we derive the new physics contributions to $(g-2)_{\mu}$ and perform the numerical analysis in Sec. III. In Sec. IV, we discuss the possible collider phenomenology. Finally, we present a summary and conclusions in Sec. V.

II. MODEL SETUP

• I. INTRODUCTION
• II. MODEL SETUP
•      A VLQ Yukawa interactions with Higgs
•      B VLQ gauge interactions
•      C VLQ Yukawa interactions with LQ
• III. CONTRIBUTIONS TO $\boldsymbol{(g-2)_{\mu}}$
•      A Analytical results of contributions
•      B Numerical analysis
• IV. LQ AND VLQ PHENOMENOLOGY AT HADRON COLLIDERS
• V. SUMMARY AND CONCLUSIONS
• APPENDIX A: LQ DECAY WIDTH FORMULAE
• APPENDIX B: VLQ DECAY WIDTH FORMULAE

Typically, there are six types of scalar LQs [35], which carry a conserved quantum number $F\equiv 3B+ L$. Here, B and L are the baryon and lepton numbers. As for the VLQs, there are seven typical representations [42]. In Table 1, we list their representations and labels.

Table 1

Table 1.  Scalar LQ (left) and VLQ (right) representations.

$S U(3)_C\times S U(2)_L\times U(1)_Y$ representation	label	F	$S U(3)_C\times S U(2)_L\times U(1)_Y$ representation	label
$(\bar{3},3,1/3)$	$S_3$	$-2$	$(3,1,2/3)$	$T_{L,R}$
$(3,2,7/6)$	$R_2$	0	$(3,1,-1/3)$	$B_{L,R}$
$(3,2,1/6)$	$\widetilde{R}_2$	0	$(3,2,7/6)$	$(X,T)_{L,R}$
$(\bar{3},1,4/3)$	$\widetilde{S}_1$	$-2$	$(3,2,1/6)$	$(T,B)_{L,R}$
			$(3,2,-5/6)$	$(B,Y)_{L,R}$
$(\bar{3},1,1/3)$	$S_1$	$-2$	$(3,3,2/3)$	$(X,T,B)_{L,R}$
$(\bar{3},1,-2/3)$	$\bar{S}_1$	$-2$	$(3,3,-1/3)$	$(T,B,Y)_{L,R}$

DownLoad: CSV

Show Table

For the six types of scalar LQs and seven types of VLQs, there can be a total of 42 combinations, which are named "$\mathrm{LQ}+ \mathrm{VLQ}$" for convenience. Only 17 of them can lead to the chiral enhancements. In Table 2, we list these models that feature the chiral enhancements. The contributons in the four models $R_2+B_{L,R}/(B,Y)_{L,R}$ and $S_1+B_{L,R}/(B,Y)_{L,R}$ are almost the same as those in the minimal $R_2$ and $S_1$ models. There are nine models $R_2+T_{L,R}/(X,T)_{L,R}/(T,B)_{L,R}/(T,B,Y)_{L,R}$ and $S_1+T_{L,R}/ (X,T)_{L,R}/(T,B)_{L,R}/(X,T,B)_{L,R}/(T,B,Y)_{L,R}$, which produce the top and top partner chiral enhancements. For the two models $R_2/S_3+(X,T,B)_{L,R}$, there are top, top partner, bottom, and bottom partner chiral enhancements at the same time. The models including T quarks were investigated in our previous work [41]. Here, we will study the pure bottom partner chirally enhanced models $\tilde{R}_2/\tilde{S}_1+ (B,Y)_{L,R}$.

Table 2

Table 2.  Chiral enhancements in the minimal LQ and LQ+VLQ models.

Model	Chiral enhancement
$R_2$	$m_t/m_{\mu}$
$S_1$	$m_t/m_{\mu}$
$R_2+B_{L,R}/(B,Y)_{L,R}$	$m_t/m_{\mu}$
$S_1+B_{L,R}/(B,Y)_{L,R}$	$m_t/m_{\mu}$
$R_2+T_{L,R}/(X,T)_{L,R}/(T,B)_{L,R}/(T,B,Y)_{L,R}$	$m_t/m_{\mu},m_T/m_{\mu}$
$S_1+T_{L,R}/(X,T)_{L,R}/(T,B)_{L,R}/(X,T,B)_{L,R}/(T,B,Y)_{L,R}$	$m_t/m_{\mu},m_T/m_{\mu}$
$R_2+(X,T,B)_{L,R}$	$m_t/m_{\mu},m_T/m_{\mu},m_b/m_{\mu},m_B/m_{\mu}$
$S_3+(X,T,B)_{L,R}$	$m_t/m_{\mu},m_T/m_{\mu},m_b/m_{\mu},m_B/m_{\mu}$
${\tilde{\bf R}_2+\bf(B,Y)_{L,R}}$	$m_b/m_{\mu},m_B/m_{\mu}$
${\tilde{\bf S}_1+\bf(B,Y)_{L,R}}$	$m_b/m_{\mu},m_B/m_{\mu}$

DownLoad: CSV

Show Table

A VLQ Yukawa interactions with Higgs

• I. INTRODUCTION
• II. MODEL SETUP
•      A VLQ Yukawa interactions with Higgs
•      B VLQ gauge interactions
•      C VLQ Yukawa interactions with LQ
• III. CONTRIBUTIONS TO $\boldsymbol{(g-2)_{\mu}}$
•      A Analytical results of contributions
•      B Numerical analysis
• IV. LQ AND VLQ PHENOMENOLOGY AT HADRON COLLIDERS
• V. SUMMARY AND CONCLUSIONS
• APPENDIX A: LQ DECAY WIDTH FORMULAE
• APPENDIX B: VLQ DECAY WIDTH FORMULAE

Let us start with the $(B,Y)_{L,R}$ related Higgs Yukawa interactions. In the gauge eigenstates, there are two interactions $\overline{Q_L}^id_R^j\phi$ and $(\overline{B_L},\overline{Y_L})d_R^j\tilde{\phi}$ and the mass term $-M_B(\bar{B}B+\bar{Y}Y)$. Here, we define the SM Higgs doublet $\tilde{\phi}\equiv {\rm i}\sigma^2\phi^{\ast}$ with $\sigma^a(a=1,2,3)$ to be the Pauli matrices. The $Q_L^i$ and $d_R^i$ ($i=1,2,3$) represent the SM quark fields. We can parametrize ϕ as $[0,(v+h)/{\sqrt{2}}]^T$ in the unitary gauge. After the electroweak symmetry breaking (EWSB), there are mixings between $d^i$ and B. For simplicity, we only consider mixing between the third generation and B quark. Thus, we can perform the following transformations to rotate b and B quarks into mass eigenstates:

Here, $s_{L,R}^b$ and $c_{L,R}^b$ are abbreviations of $\sin\theta_{L,R}^b$ and $\cos\theta_{L,R}^b$, respectively. In fact, $\theta_L^b$ can be correlated with $\theta_R^b$ through the relation $\tan\theta_L^b=m_b\tan\theta_R^b/m_B$ [42]. Here, $m_b$ and $m_B$ represent the physical b and B quark masses, respectively. Additionally, the mass of the Y quark is $m_Y=M_B=$ $\sqrt{m_B^2(c_R^b)^2+m_b^2(s_R^b)^2}$. Then, we can choose $m_B$ and $\theta_R^b$ as the new input parameters. After the transformations in Eq. (1), we obtain the following mass eigenstate Higgs Yukawa interactions:

Note that the Y quark does not interact with Higgs at the tree level.

B VLQ gauge interactions

• I. INTRODUCTION
• II. MODEL SETUP
•      A VLQ Yukawa interactions with Higgs
•      B VLQ gauge interactions
•      C VLQ Yukawa interactions with LQ
• III. CONTRIBUTIONS TO $\boldsymbol{(g-2)_{\mu}}$
•      A Analytical results of contributions
•      B Numerical analysis
• IV. LQ AND VLQ PHENOMENOLOGY AT HADRON COLLIDERS
• V. SUMMARY AND CONCLUSIONS
• APPENDIX A: LQ DECAY WIDTH FORMULAE
• APPENDIX B: VLQ DECAY WIDTH FORMULAE

Now, let us label the $S U(2)_L$ and $U_Y(1)$ gauge fields as $W_{\mu}^a$ and $B_{\mu}$. Then, the electroweak covariant derivative $D_{\mu}$ is defined as $\partial_{\mu}-{\rm i}gW_{\mu}^a\sigma^a/2-{\rm i}g^{\prime}Y_qB_{\mu}$ for a doublet and $\partial_{\mu}-{\rm i}g^{\prime}Y_qB_{\mu}$ for a singlet, in which $Y_q$ is the $U_Y(1)$ charge of the quark field acted by $D_{\mu}$. Thus, the related gauge interactions can be written as $\overline{Q_L}^iiD_{\mu}\gamma^{\mu}Q_L^i+ \overline{d_R}^iiD_{\mu}\gamma^{\mu}d_R^i+(\overline{B},\overline{Y})iD_{\mu}\gamma^{\mu}(B,Y)^T$. After the EWSB, the W gauge interactions can be written as

The Z gauge interactions can be written as

After the rotations in Eq. (1), we have the mass eigenstate W gauge interactions:

We also have the mass eigenstate Z gauge interactions:

C VLQ Yukawa interactions with LQ

• I. INTRODUCTION
• II. MODEL SETUP
•      A VLQ Yukawa interactions with Higgs
•      B VLQ gauge interactions
•      C VLQ Yukawa interactions with LQ
• III. CONTRIBUTIONS TO $\boldsymbol{(g-2)_{\mu}}$
•      A Analytical results of contributions
•      B Numerical analysis
• IV. LQ AND VLQ PHENOMENOLOGY AT HADRON COLLIDERS
• V. SUMMARY AND CONCLUSIONS
• APPENDIX A: LQ DECAY WIDTH FORMULAE
• APPENDIX B: VLQ DECAY WIDTH FORMULAE

Let us denote the SM lepton fields as $L_L^i$ and $e_R^i$. The $\tilde{R}_2$ can be parametrized as $[\tilde{R}_2^{2/3},\tilde{R}_2^{-1/3}]^T$, where the superscript labels the electric charge. Then, the $\tilde{R}_2$ and $\tilde{S}_1$ can induce the following $F=0$ and $F=2$ type gauge eigenstate LQ Yukawa interactions:

and

After the EWSB, they can be parametrized as

and

In the above, we define the chiral operators $\omega_{\pm}$ as $(1\pm\gamma^5)/2$. After the rotations in Eq. (1), we have the mass eigenstate interactions:

and

III. CONTRIBUTIONS TO $\boldsymbol{(g-2)_{\mu}}$

• I. INTRODUCTION
• II. MODEL SETUP
•      A VLQ Yukawa interactions with Higgs
•      B VLQ gauge interactions
•      C VLQ Yukawa interactions with LQ
• III. CONTRIBUTIONS TO $\boldsymbol{(g-2)_{\mu}}$
•      A Analytical results of contributions
•      B Numerical analysis
• IV. LQ AND VLQ PHENOMENOLOGY AT HADRON COLLIDERS
• V. SUMMARY AND CONCLUSIONS
• APPENDIX A: LQ DECAY WIDTH FORMULAE
• APPENDIX B: VLQ DECAY WIDTH FORMULAE

A Analytical results of contributions

• I. INTRODUCTION
• II. MODEL SETUP
•      A VLQ Yukawa interactions with Higgs
•      B VLQ gauge interactions
•      C VLQ Yukawa interactions with LQ
• III. CONTRIBUTIONS TO $\boldsymbol{(g-2)_{\mu}}$
•      A Analytical results of contributions
•      B Numerical analysis
• IV. LQ AND VLQ PHENOMENOLOGY AT HADRON COLLIDERS
• V. SUMMARY AND CONCLUSIONS
• APPENDIX A: LQ DECAY WIDTH FORMULAE
• APPENDIX B: VLQ DECAY WIDTH FORMULAE

For the $\mathrm{LQ}\mu q$ interaction, there are quark-photon and LQ-photon vertex mediated contributions to $(g-2)_{\mu}$, which can be described by the functions $f^q(x)$ and $f^S(x)$. Then, we use the functions $f_{LL}^{q,S}(x)$ and $f_{LR}^{q,S}(x)$ to label the parts without and with chiral enhancements. Starting from the $f_{LL}^{q,S}(x)$ and $f_{LR}^{q,S}(x)$ given in our previous paper [41], let us define the following integrals:

For the $\tilde{R}_2+(B,Y)_{L,R}$ model, there are b, B, and Y quark contributions to the $(g-2)_{\mu}$. The complete expression is calculated as

At the tree level, we have $m_{\tilde{R}_2^{2/3}}=m_{\tilde{R}_2^{-1/3}}\equiv m_{\tilde{R}_2}$. Compared with the bottom partner chirally enhanced contribution (i.e., the $f_{LR}^{\tilde{R}_2\mu b}\left(\dfrac{m_B^2}{m_{\tilde{R}_2^{2/3}}^2}\right)$ related term), the non-chirally enhanced parts are suppressed by the factor $m_{\mu}/(m_Bs_R^b)\sim1/(10^4s_R^b)$ and the bottom quark chirally enhanced part is suppressed by the factor $(m_bs_L^b)/(m_Bs_R^b) \sim(m_b^2/m_B^2)$. For the interesting values of $s_R^b$ at $\mathcal{O}(0.01\sim0.1)$, $\Delta a_{\mu}^{\tilde{R}_2+BY}$ is dominated by the bottom partner chirally enhanced contribution. Then, the above expression can be approximated as

For the $\tilde{S}_1+(B,Y)_{L,R}$ model, there are b and B quark contributions to $(g-2)_{\mu}$. The complete expression is calculated as

Similarly, it can be approximated as

B Numerical analysis

• I. INTRODUCTION
• II. MODEL SETUP
•      A VLQ Yukawa interactions with Higgs
•      B VLQ gauge interactions
•      C VLQ Yukawa interactions with LQ
• III. CONTRIBUTIONS TO $\boldsymbol{(g-2)_{\mu}}$
•      A Analytical results of contributions
•      B Numerical analysis
• IV. LQ AND VLQ PHENOMENOLOGY AT HADRON COLLIDERS
• V. SUMMARY AND CONCLUSIONS
• APPENDIX A: LQ DECAY WIDTH FORMULAE
• APPENDIX B: VLQ DECAY WIDTH FORMULAE

The input parameters are chosen as $m_\mu=105.66~\mathrm{MeV}$, $m_b=4.2 ~\mathrm{GeV}$, $m_t=172.5 ~\mathrm{GeV}$, $G_F=1.1664\times10^{-5} ~\mathrm{GeV}^{-2}$, $m_W=80.377 ~\mathrm{GeV}$, $m_Z=91.1876 ~\mathrm{GeV}$, and $m_h=125.25 \mathrm{GeV}$ [43]. The $v,\;g,\;\theta_W$ are defined by $G_F=1/(\sqrt{2}v^2), g=2m_W/v,~\cos\theta_W\equiv c_W=m_W/m_Z$. There are also new parameters $m_B$, $m_{ \mathrm{LQ}}$, $\theta_R^b$, and the LQ Yukawa couplings $y_{L,R}^{ \mathrm{LQ}\mu q}$. The VLQ mass can be constrained from the direct search, which is required to be above $1.5~ \mathrm{TeV}$ [44−47]. The mixing angle is mainly bounded by the electro-weak precision observables (EWPOs). The VLQ contributions to T parameter are suppressed by the factor $(s_R^b)^4$ or $m_b^2(s_R^b)^2/m_B^2$ [48, 49], which leads to a less constrained $\theta_R^b$. The weak isospin third component of $B_R$ is positive; thus, the mixing with the bottom quark enhances the right-handed $Zbb$ coupling. As a result, the $A_{FB}^b$ deviation [50, 51] can be compensated, which leads to looser constraints on $\theta_R^b$. Conservatively, we can choose the mixing angle $s_R^b$ to be smaller than $0.1$ [42]. The LQ mass can also be constrained from the direct search, which is required to be above $1.7 ~\mathrm{TeV}$ assuming $\mathrm{Br}(\mathrm{LQ}\rightarrow b\mu)=1$ [52, 53].

We can choose benchmark points of $m_B,m_{ \mathrm{LQ}},s_R^b$ to constrain the LQ Yukawa couplings. Here, we consider two scenarios: $m_{ \mathrm{LQ}}>m_B$ and $m_{ \mathrm{LQ}}<m_B$. For the scenario of $m_{ \mathrm{LQ}}>m_B$, we adopt mass parameters of $m_B=$ 1.5 TeV and $m_{ \mathrm{LQ}}=2 ~\mathrm{TeV}$. For the scenario of $m_{ \mathrm{LQ}}<m_B$, we adopt mass parameters of $m_B=$ 2.5 TeV and $m_{ \mathrm{LQ}}=2 ~\mathrm{TeV}$. In Table 3, we give the approximate numerical expressions of $\Delta a_{\mu}$ in the $\tilde{R}_2/\tilde{S}_1+(B,Y)_{L,R}$ models. We also show the allowed ranges for $s_R^b=0.1$ and $s_R^b=0.05$. Of course, these behaviours can be understood from Eqs. (15) and (17). In the $\tilde{R}_2+(B,Y)_{L,R}$ model, $f_{LR}^{\tilde{R}_2\mu b}(x)$ vanishes when $m_B= m_{\tilde{R}_2}$, which causes the $| \mathrm{Re}[y_L^{\tilde{R}_2\mu B}(y_R^{\tilde{R}_2\mu b})^\ast]|$ to be under the stress of perturbative unitarity. If there is a large hierarchy between $m_B$ and $m_{\tilde{R}_2}$, the allowed $| \mathrm{Re}[y_L^{\tilde{R}_2\mu B}(y_R^{\tilde{R}_2\mu b})^\ast]|$ can be smaller. Additionally, $\mathrm{Re}[y_L^{\tilde{R}_2\mu B}(y_R^{\tilde{R}_2\mu b})^\ast]$ should be positive (negative) when $m_B<m_{\tilde{R}_2}$ ($m_B>m_{\tilde{R}_2}$). In the $\tilde{S}_1+(B,Y)_{L,R}$ model, $f_{LR}^{\tilde{S}_1\mu b}(x)$ is always negative, which requires $\mathrm{Re}[y_R^{\tilde{S}_1\mu B}(y_L^{\tilde{S}_1\mu b})^\ast]<0$.

Table 3

Table 3.  In the third column, we show the leading order numerical expressions of the $\Delta a_{\mu}$. In the fifth and sixth columns, we show the ranges allowed by $(g-2)_{\mu}$ at $1\sigma$ and $2\sigma$ confidence levels (CLs).

Model	$(m_B,m_{ \mathrm{LQ}})/ \mathrm{TeV}$	$\Delta a_{\mu}\times10^7$	$s_R^b$	$\mathrm{Re}[y_L^{\tilde{R}_2\mu B}(y_R^{\tilde{R}_2\mu b})^\ast]$ or $\mathrm{Re}[y_R^{\tilde{S}_1\mu B}(y_L^{\tilde{S}_1\mu b})^\ast]$
				$1\sigma$	$2\sigma$
$\tilde{R}_2+(B,Y)_{L,R}$	$(1.5,2)$	$0.35s_R^b \mathrm{Re}[y_L^{\tilde{R}_2\mu B}(y_R^{\tilde{R}_2\mu b})^\ast]$	0.1	$(0.55,0.88)$	$(0.38,1.05)$
			0.05	$(1.1,1.77)$	$(0.76,2.11)$
	$(2.5,2)$	$-0.224s_R^b \mathrm{Re}[y_L^{\tilde{R}_2\mu B}(y_R^{\tilde{R}_2\mu b})^\ast]$	0.1	$(-1.38,-0.86)$	$(-1.65,-0.59)$
			0.05	$(-2.76,-1.71)$	$(-3.29,-1.19)$
$\tilde{S}_1+(B,Y)_{L,R}$	$(1.5,2)$	$-6.88s_R^b \mathrm{Re}[y_R^{\tilde{S}_1\mu B}(y_L^{\tilde{S}_1\mu b})^\ast]$	0.1	$(-0.045,-0.028)$	$(-0.054,-0.019)$
			0.05	$(-0.09,-0.056)$	$(-0.11,-0.039)$
	$(2.5,2)$	$-6.37s_R^b \mathrm{Re}[y_R^{\tilde{S}_1\mu B}(y_L^{\tilde{S}_1\mu b})^\ast]$	0.1	$(-0.049,-0.03)$	$(-0.058,-0.021)$
			0.05	$(-0.097,-0.06)$	$(-0.12,-0.042)$

DownLoad: CSV

Show Table

We can also choose benchmark points of $s_R^b$ and LQ Yukawa couplings to constrain the $m_B$ and $m_{ \mathrm{LQ}}$. Fig. 1 presents the $(g-2)_{\mu}$ allowed regions in the plane of $m_B-m_{ \mathrm{LQ}}$. As shown, $m_B<m_{\tilde{R}_2}$ and $m_B>m_{\tilde{R}_2}$ are favored in the left and middle plots, respectively. This can be understood from the asymptotic behaviours $f_{LR}^{\tilde{R}_2\mu b}(x)\sim -\log(x)/2 > 0$ for $x\rightarrow0$ and $f_{LR}^{\tilde{R}_2\mu b}(x) \sim-1/(4x) < 0$ for $x\rightarrow \infty$. To produce a positive $\Delta a_{\mu}$, $m_B<m_{\tilde{R}_2}$ and $m_B>m_{\tilde{R}_2}$ are favored for $\mathrm{Re}[y_L^{\tilde{R}_2\mu B}(y_R^{\tilde{R}_2\mu b})^\ast]>0$ and $\mathrm{Re}[y_L^{\tilde{R}_2\mu B}(y_R^{\tilde{R}_2\mu b})^\ast]<0$, respectively. The $f_{LR}^{\tilde{S}_1\mu b}(x)$ has asymptotic behaviours $f_{LR}^{\tilde{S}_1\mu b}(x)\sim \log(x)/2 < 0$ for $x\rightarrow0$ and $f_{LR}^{\tilde{S}_1\mu b}(x)\sim-5/(4x) < 0$ for $x\rightarrow \infty$. To produce a positive $\Delta a_{\mu}$, $\mathrm{Re}[y_R^{\tilde{S}_1\mu B}(y_L^{\tilde{S}_1\mu b})^\ast]<0$ is favored. Furthermore, the allowed regions in the plane of $m_B-m_{ \mathrm{LQ}}$ are sensitive to the choice of $y_{L,R}^{ \mathrm{LQ}\mu q}$. Generally, a larger $|y_{L,R}^{ \mathrm{LQ}\mu q}|$ corresponds to a larger $m_B$ and $m_{ \mathrm{LQ}}$.

Figure 1

Figure 1.  (color online) $(g-2)_{\mu}$ allowed regions at $1\sigma$ (green) and $2\sigma$ (yellow) CLs with $s_R^b=0.1$. The parameters are chosen as $y_L^{\tilde{R}_2\mu B}=y_R^{\tilde{R}_2\mu b}=0.8$ in the $\tilde{R}_2+(B,Y)$ model (left), $y_L^{\widetilde{R}_2\mu B}=-y_R^{\tilde{R}_2\mu b}=0.8$ in the $\tilde{R}_2+(B,Y)$ model (middle), and $y_L^{\tilde{S}_1\mu b}=-y_R^{\tilde{S}_1\mu B}=0.2$ in the $\tilde{S}_1+(B,Y)$ model (right).

DownLoad: Full-Size Img PowerPoint

IV. LQ AND VLQ PHENOMENOLOGY AT HADRON COLLIDERS

• I. INTRODUCTION
• II. MODEL SETUP
•      A VLQ Yukawa interactions with Higgs
•      B VLQ gauge interactions
•      C VLQ Yukawa interactions with LQ
• III. CONTRIBUTIONS TO $\boldsymbol{(g-2)_{\mu}}$
•      A Analytical results of contributions
•      B Numerical analysis
• IV. LQ AND VLQ PHENOMENOLOGY AT HADRON COLLIDERS
• V. SUMMARY AND CONCLUSIONS
• APPENDIX A: LQ DECAY WIDTH FORMULAE
• APPENDIX B: VLQ DECAY WIDTH FORMULAE

In Table 4, we list the main LQ and VLQ decay channels ². The decay formulae of LQ and VLQ are given in Appendices A and B, respectively. For the scenario of $m_{ \mathrm{LQ}}>m_B$, there are new LQ decay channels. When searching for the LQ $\tilde{R}_2^{2/3}$, we propose the $\mu j_bZ$ and $\mu j_bh$ signatures. When searching for the LQ $\tilde{R}_2^{-1/3}$, we propose the $\mu j_bW$ signatures. When searching for the LQ $\tilde{S}_1$, we propose the $\mu j_bZ$, $\mu j_bh$, $\not {E_T}j_bW$ signatures. For the scenario of $m_{ \mathrm{LQ}}<m_B$, there are new VLQ decay channels. When searching for the VLQ B, we propose the $\mu^+\mu^-j_b$ signatures. When searching for the VLQ Y, we propose the $\mu\; \not {E_T}j_b$ signatures. It seems that such decay channels have not been searched for by the experimental collaborations.

Table 4

Table 4.  In the third column, we show the main LQ decay channels. In the fourth column, we show the main VLQ decay channels. In the fifth column, we show the new LQ or VLQ signatures.

Model	Scenario	LQ decay	VLQ decay	new signatures
$\tilde{R}_2+(B,Y)_{L,R}$	$m_{ \mathrm{LQ}}>m_B$	$\tilde{R}_2^{2/3}\rightarrow \mu^+b,\mu^+B$	$B\rightarrow bZ,bh$	$\tilde{R}_2^{2/3}\rightarrow \mu j_bZ,\mu j_bh$
		$\tilde{R}_2^{-1/3}\rightarrow \mu^+Y,\nu_Lb$	$Y\rightarrow bW^-$	$\tilde{R}_2^{-1/3}\rightarrow \mu j_bW$
	$m_{ \mathrm{LQ}}<m_B$	$\tilde{R}_2^{2/3}\rightarrow \mu^+b$	$B\rightarrow bZ,bh,\mu^-\tilde{R}_2^{2/3}$	$B\rightarrow \mu^+\mu^-j_b$
		$\tilde{R}_2^{-1/3}\rightarrow \nu_Lb$	$Y\rightarrow bW^-,\mu^-\tilde{R}_2^{-1/3}$	$Y\rightarrow \mu \not {E_T}j_b$
$\tilde{S}_1+(B,Y)_{L,R}$	$m_{ \mathrm{LQ}}>m_B$	$\tilde{S}_1\rightarrow \mu^+\bar{b},\mu^+\bar{B},\nu_L\bar{Y}$	$B\rightarrow bZ,bh$	$\tilde{S}_1\rightarrow \mu j_bZ$, $\mu j_bh$, $\not {E_T}j_bW$
			$Y\rightarrow bW^-$
	$m_{ \mathrm{LQ}}<m_B$	$\tilde{S}_1\rightarrow \mu^+\bar{b}$	$B\rightarrow bZ,bh,\mu^+(\tilde{S}_1)^{\ast}$	$B\rightarrow \mu^+\mu^-j_b$
			$Y\rightarrow bW^-,\nu_L(\tilde{S}_1)^{\ast}$	$Y\rightarrow \mu \not {E_T}j_b$

DownLoad: CSV

Show Table

To estimate the effects of new decay channels, we will compare the ratios of new partial decay widths with the traditional ones. Because of gauge symmetry, the different partial decay widths can be correlated. Then, we choose the following four ratios:

In Fig. 2, we show the contour plots of above four ratios under the consideration of $(g-2)_{\mu}$ constraints. In these plots, we include the full contributions. We find that the new LQ decay channels can become important for larger $|y_L^{\tilde{R}_2\mu B}|$ in the $\tilde{R}_2+(B,Y)_{L,R}$ model and $|y_R^{\tilde{S}_1\mu B}|$ in the $\tilde{S}_1+(B,Y)_{L,R}$ model. As for the VLQ decay, the importance of new decay channels depends significantly on $s_R^b$. For $s_R^b=0.1$ and $m_B=2.5 ~\mathrm{TeV}$, the new VLQ decay channels are less significant. For smaller $s_R^b$, the new VLQ decay channels can play an important role.

Figure 2

Figure 2.  (color online) Contour plots of $\log_{10}\frac{\Gamma(\tilde{R}_2^{2/3}\rightarrow \mu^+B)}{\Gamma(\tilde{R}_2^{2/3}\rightarrow \mu^+b)}$ (upper left), $\log_{10}\frac{\Gamma(\tilde{S}_1\rightarrow \mu^+\bar{B})}{\Gamma(\tilde{S}_1\rightarrow \mu^+\bar{b})}$ (lower left), $\log_{10}\frac{\Gamma(B\rightarrow \mu^-\tilde{R}_2^{2/3})}{\Gamma(B\rightarrow bh)}$ (upper right), and $\log_{10}\frac{\Gamma(B\rightarrow \mu^+(\tilde{S}_1)^{\ast})}{\Gamma(B\rightarrow bh)}$ (lower right), where the colored regions are allowed by the $(g-2)_{\mu}$ at $2\sigma$ CL. For the LQ decay, we choose $m_B=1.5 ~\mathrm{TeV}$ and $m_{ \mathrm{LQ}}=2 ~\mathrm{TeV}$. For the VLQ decay, we choose $m_B=2.5 ~\mathrm{TeV}$ and $m_{ \mathrm{LQ}}=2 ~\mathrm{TeV}$.

DownLoad: Full-Size Img PowerPoint

For the LQ and VLQ production at hadron colliders, there are pair and single production channels, which are very sensitive to the LQ and VLQ masses. We can adopt the FeynRules [54] to generate the model files and compute the cross sections with MadGraph5${}_{-}$aMC@NLO [55]. For the 2 TeV scale LQ pair production [56−58], the cross section can be $\sim0.01 ~\mathrm{fb}$ at the 13 TeV LHC. For the 1.5 TeV and 2.5 TeV scale VLQ pair production [59−61], the cross section can be $\sim2~ \mathrm{fb}$ and $\sim0.01~ \mathrm{fb}$ at the 13 TeV LHC. For the single LQ and VLQ production channels, they depend on the electroweak couplings [42, 62, 63]. In the parameter space of large LQ Yukawa couplings, the single LQ production can be important, which may give some constraints at HL-LHC. To generate enough events, higher energy hadron colliders, for example, 27 and 100 TeV, can be necessary. In addition to the collider direct search, there can be indirect footprints, for example, B physics related decay modes $\Upsilon\rightarrow \mu^+\mu^-,\nu\bar{\nu}\gamma$. If we consider a more complex flavour structure (e.g., turn on the $\mathrm{LQ}\mu s$ interaction), this can affect the $B\rightarrow K\mu^+\mu^-$ channel. Here, we will not study this detailed phenomenology.

V. SUMMARY AND CONCLUSIONS

• I. INTRODUCTION
• II. MODEL SETUP
•      A VLQ Yukawa interactions with Higgs
•      B VLQ gauge interactions
•      C VLQ Yukawa interactions with LQ
• III. CONTRIBUTIONS TO $\boldsymbol{(g-2)_{\mu}}$
•      A Analytical results of contributions
•      B Numerical analysis
• IV. LQ AND VLQ PHENOMENOLOGY AT HADRON COLLIDERS
• V. SUMMARY AND CONCLUSIONS
• APPENDIX A: LQ DECAY WIDTH FORMULAE
• APPENDIX B: VLQ DECAY WIDTH FORMULAE

In this study, we investigate the scalar LQ and VLQ extended models to explain the $(g-2)_{\mu}$ anomaly. Then, we find two new models $\tilde{R}_2/\tilde{S}_1+(B,Y)_{L,R}$, which can lead to the B quark chiral enhancements because of the bottom and bottom partner mixing. In the numerical analysis, we consider two scenarios: $m_{ \mathrm{LQ}}>m_B$ and $m_{ \mathrm{LQ}}<m_B$. After considering the experimental constraints, we choose relative light masses, which are adopted to be $(m_B,m_{ \mathrm{LQ}})=(1.5 ~\mathrm{TeV},2 ~\mathrm{TeV})$ for the first scenario and $(m_B,m_{ \mathrm{LQ}})=(2.5 ~\mathrm{TeV},2~ \mathrm{TeV})$ for the second scenario. In the $\tilde{R}_2+(B,Y)_{L,R}$ model, the $| \mathrm{Re}[y_L^{\tilde{R}_2\mu B}(y_R^{\tilde{R}_2\mu b})^\ast]|$ is bounded to be $\mathcal{O}(1)$, because $f_{LR}^{\tilde{R}_2\mu b}(x)$ vanishes accidentally as $m_B= m_{\tilde{R}_2}$. Meanwhile, we can expect smaller $| \mathrm{Re}[y_L^{\tilde{R}_2\mu B}(y_R^{\tilde{R}_2\mu b})^\ast]|$ for largely splitted $m_{\tilde{R}_2}$ and $m_B$. In the $\tilde{S}_1+(B,Y)_{L,R}$ model, the $\mathrm{Re}[y_R^{\tilde{S}_1\mu B}(y_L^{\tilde{S}_1\mu b})^\ast]$ is bounded to the range $(-0.06, -0.02)$ at a $2\sigma$ CL if $s_R^b=0.1$.

Under the constraints from $(g-2)_{\mu}$, we propose new LQ and VLQ search channels. In the scenario of $m_{ \mathrm{LQ}}>m_B$, there are new LQ decay channels: $\tilde{R}_2^{2/3}\rightarrow \mu^+B$, $\tilde{R}_2^{-1/3}\rightarrow \mu^+Y$, and $\tilde{S}_1\rightarrow \mu^+\bar{B},\nu_L\bar{Y}$. For larger $y_L^{\tilde{R}_2\mu B}$ and $y_R^{\tilde{S}_1\mu B}$, it is important to take into account these decay channels. In the scenario of $m_{ \mathrm{LQ}}<m_B$, there are new VLQ decay channels: $B\rightarrow \mu^-\tilde{R}_2^{2/3},\mu^+(\tilde{S}_1)^{\ast}$ and $Y\rightarrow \mu^-\tilde{R}_2^{-1/3},~ \nu_L(\tilde{S}_1)^{\ast}$. For $s_R^b=0.1$, these channels are negligible compared with the traditional $B\rightarrow bZ,~bh$ and $Y\rightarrow bW^-$ channels. For smaller $s_R^b$, these new VLQ decay channels can also become important.

Note added: In a prevoius study [64], the authors examined the model with $\tilde{R}_2$, $S_3$, and $(B,Y)_{L,R}$. In this work, they did not consider the bottom and B quark mixing, and the chiral enhancements were produced through the $\tilde{R}_2$ and $S_3$ mixing. In [65], the authors explained the $(g-2)_{\mu}$ and B physics anomalies in the $S_1+(B,Y)_{L,R}$ model.

APPENDIX A: LQ DECAY WIDTH FORMULAE

• I. INTRODUCTION
• II. MODEL SETUP
•      A VLQ Yukawa interactions with Higgs
•      B VLQ gauge interactions
•      C VLQ Yukawa interactions with LQ
• III. CONTRIBUTIONS TO $\boldsymbol{(g-2)_{\mu}}$
•      A Analytical results of contributions
•      B Numerical analysis
• IV. LQ AND VLQ PHENOMENOLOGY AT HADRON COLLIDERS
• V. SUMMARY AND CONCLUSIONS
• APPENDIX A: LQ DECAY WIDTH FORMULAE
• APPENDIX B: VLQ DECAY WIDTH FORMULAE

When the $\tilde{R}_2$ masses are degenerate, there are no gauge boson decay channels such as $\tilde{R}_2^{2/3}\rightarrow \tilde{R}_2^{-1/3}W^+$. For the $\tilde{R}_2^{2/3}$ to $\mu^+b$ and $\mu^+B$ decay channels, the widths are calculated as

For the $\tilde{R}_2^{-1/3}$ to $\mu^+Y,\nu_Lb,\nu_LB$ decay channels, the widths are calculated as

Considering $m_{\mu},m_b\ll m_B$ and $\theta_{L,R}^b\ll1$, we have the following approximations:

For the $\tilde{S}_1$ to $\mu^+\bar{b},\mu^+\bar{B},\nu_L\bar{Y}$ decay channels, the widths are calculated as

Considering $m_{\mu},m_b\ll m_B$ and $\theta_{L,R}^b\ll1$, we have the following approximations:

APPENDIX B: VLQ DECAY WIDTH FORMULAE

• I. INTRODUCTION
• II. MODEL SETUP
•      A VLQ Yukawa interactions with Higgs
•      B VLQ gauge interactions
•      C VLQ Yukawa interactions with LQ
• III. CONTRIBUTIONS TO $\boldsymbol{(g-2)_{\mu}}$
•      A Analytical results of contributions
•      B Numerical analysis
• IV. LQ AND VLQ PHENOMENOLOGY AT HADRON COLLIDERS
• V. SUMMARY AND CONCLUSIONS
• APPENDIX A: LQ DECAY WIDTH FORMULAE
• APPENDIX B: VLQ DECAY WIDTH FORMULAE

If $m_B\sim \mathrm{TeV}$ and $\theta_R^b\ll0.1$, we have $m_B-m_Y\approx m_B(s_R^b)^2/2\lesssim5 ~\mathrm{GeV}$, which leads to the kinematic prohibition of some decay channels. For the $Y\rightarrow bW^-$ decay channel, the width is calculated as

For the $B\rightarrow bZ,~bh,~tW^-$ decay channels, the widths are calculated as

Considering $m_b,~m_t,~m_Z,~m_W\ll m_B$ and $\theta_{L,R}^b\ll1$, we have the following approximations:

In the $\tilde{R}_2+(B,Y)_{L,R}$ model, the VLQ can also decay into the $\tilde{R}_2$ final state. For the $Y\rightarrow \mu^-\tilde{R}_2^{-1/3}$ decay channel, the width is calculated as

For the $B\rightarrow \mu^-\tilde{R}_2^{2/3},~\nu_L\tilde{R}_2^{-1/3}$ decay channels, the widths are calculated as

Considering $m_{\mu}\ll m_B$ and $\theta_{L,R}^b\ll1$, we have the following approximations:

In the $\tilde{S}_1+(B,Y)_{L,R}$ model, the VLQ can also decay into the $\tilde{S}_1$ final state. For the $Y\rightarrow \nu_L(\tilde{S}_1)^{\ast}$ decay channel, the width is calculated as

For the $B\rightarrow \mu^+(\tilde{S}_1)^{\ast}$ decay channel, the width is calculated as

Considering $m_{\mu}\ll m_B$ and $\theta_{L,R}^b\ll1$, we have the following approximations:

1The terminology VLQ should not be confused with the vector leptoquark in some bibliographies.

2The $$\begin{document}$ \tilde{R}_2^{-1/3}\rightarrow \nu_LB $\end{document}$$ and $$\begin{document}$ B\rightarrow \nu_L\tilde{R}_2^{-1/3} $\end{document}$$ decay channels are suppressed by the factor $$\begin{document}$ (s_R^b)^2 $\end{document}$$ . The $$\begin{document}$ B\rightarrow tW^- $\end{document}$$ decay channel is suppressed by the factor $$\begin{document}$ m_b^2/m_B^2 $\end{document}$$ .

References
